Reset
VDDD
R25
4.7K
XRES_L
C39
0.1uF
10V
CINT, CMOD & CSH
P7_1
C2 0.47nF
CINTA
25V
P7_2
C3 0.47nF
CINTB Optional CSH
25V
4
P7_7
C5 2.2nF
CMOD
25V
Supply for Type 1DX Module
VBAT
U2A
30
VBAT
VDDIO_WL
36
VIO
2.2uH
34
L3
SR_VLX
31
VIN_LDO
C29
GND_SR_PVSS1
4.7uF
GND_SR_PVSS2
16V
LBEE5KL1DX-883
WCO
C32 22pF
P0_1
25V
Y 2
32.768KHz
C33 22pF
P0_0
25V
ECO
P12_6
Y 1 C22
17.2032MHz 10pF
25V
2
C26
10pF
25V
P12_7
1
GND1
12
GND2
19
GND3
21
GND4
29
GND5
35
GND6
40
GND7
42
GND8
43
GND9
44
GND10
45
GND11
46
GND12
32
33
