RoboLabs Mini Robopop 25 Instruction Manual page 10

3.3 Electric requirements
The machine requires single phase 230 V 50 Hz three-wire system (L-N-GND). Use 2P+PE 32 A
250 V pin and sleeve connector (IEC 60309). Connecting to the mains must be arranged in
conformity with all requirements applicable in the country of use at the moment of
commissioning. The machine has a 32 A 2P circuit breaker with rated short-circuit capacity 6
kA at its input.
Equipotential bonding wire (up to 10 sq.mm) shall be connected to screw terminal on the base
frame marked with IEC 60417-5021 sign: IEC 60417-5021:
Check the voltage in the receptacle. Plug the machine in. Make sure that the supply cord is not
twisted, pulled, and is not mechanically impacted in any other way; and also is not in contact
with hot surfaces.
3.4 First start (operation check)
ATTENTION! Machine that was kept for a long time at temperatures below 0 °C must be kept
in normal room temperature (20-22 °C) not less than 12 hours before first start.
Follow these steps to check the machine operation:
1. Release the Emergency stop switch (if actuated).
2. Turn the machine on, process 1-2 batches of corn, acting as described in Operating
order section.
3. Turn the machine off and unplug.
9
