2 Specifications
2.1 Core System

CPU: 12th Generation Intel® Core™ i9/i7/i5/i3 Desktop Processor
•
Intel® Core™ i9-12900E, up to 5.00 GHz, 16 Core, 30M Cache, DDR5 4800 MT/s support, 65W
•
Intel® Core™ i9-12900TE, up to 4.80 GHz, 16 Core, 30M Cache, DDR5 4800 MT/s support, 35W
•
Intel® Core™ i7-12700E, up to 4.80 GHz, 12 Core, 25M Cache, DDR5 4800 MT/s support, 65W
•
Intel® Core™ i7-12700TE, up to 4.60 GHz, 12 Core, 25M Cache, DDR5 4800 MT/s support, 35W
•
Intel® Core™ i5-12500E, up to 4.50 GHz, 6 Core, 18M Cache, DDR5 4800 MT/s support, 65W
•
Intel® Core™ i5-12500TE, up to 4.30 GHz, 6 Core, 18M Cache, DDR5 4800 MT/s support, 35W
•
Intel® Core™ i3-12100E, up to 4.20 GHz, 4 Core, 12M Cache, DDR5 4800 MT/s support, 60W
•
Intel® Core™ i3-12100TE, up to 4.00 GHz, 4 Core, 12M Cache, DDR5 4800 MT/s support, 35W
•
Intel® Pentium® Gold G7400E, up to 3.60 GHz, 2 Core, 6M Cache, DDR5 4800 MT/s support, 46W
•
Intel® Pentium® Gold G7400TE, up to 3.00 GHz, 2 Core, 6M Cache, DDR5 4800 MT/s support, 35W
•
Intel® Celeron® G6900E, up to 3.00 GHz, 2 Core, 4M Cache, DDR5 4800 MT/s support, 46W
•
Intel® Celeron® G6900TE, up to 2.40 GHz, 2 Core, 4M Cache, DDR5 4800 MT/s support, 35W

Chipset: Intel® H610E Chipset

Memory: 2x 288-pin DDR5 non-ECC sockets, dual-channel DDR5 4800 MHz, up to 64 GB

BIOS: AMI® UEFI BIOS, 256 Mb SPI Flash Memory

Hardware Monitor
•
+3.3 V voltage
•
+5 V voltage
•
+12 V voltage
•
CPU temperature
•
System temperature
•
CPU fan speed
•
System fan speed
2.2 I/O Interface

Expansion Slots
•
1x PCIe x16 Gen5
•
1x PCIe x4 Gen3
•
1x PCIe x1 Gen3
•
4x PCI

LAN
•
LAN1: I219-LM supports 1Gbps / 100Mbps / 10Mbps
•
LAN2: I225-V supports 2.5Gps / 1Gbps / 100Mbps / 10Mbps

SATA: 3x SATA 6.0 Gb/s connectors
