JB Systems LED PAR64FC ZOOM Operation Manual page 9

ENGLISH
• Press the ENTER button to save your setting.
MASTER
Used to set the master dimmer while used as master.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to select the desired level for the master dimmer. (please note that the last selected
static color will be used to set the value)
• Once you have the desired level, press the ENTER button to save it.
Note: the setting of this option has NO effect while the projector is used as SLAVE or in DMX-mode.
WHITEBAL
Used to set the white balance or to perfectly match the colors of several projectors.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the display shows the value (050-255) for RED. (change with ▲/▼buttons)
• Press the ENTER button: the display shows the value (050-255) for GREEN. (change with ▲/▼buttons)
• Press the ENTER button: the display shows the value (050-255) for BLUE. (change with ▲/▼buttons)
• Press the ENTER button: the display shows the value (050-255) for LIME. (change with ▲/▼buttons)
• Once you have set the desired levels, press the ENTER button to save them.
Note: the setting of this option affects all color settings, static colors and DMX-controlled colors.
DIMCURVE
Used to set the dimmer curve of the master dimmer.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to selected the desired curve:
• Once you have the desired curve, press the ENTER button to save it.
BEHAVIOR
Used to select the reaction time of the projector.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to select the desired mode:
• LED
• HALOGEN
• Once the correct option shows on the display, press the ENTER button to save it.
FANSPEED
Used to set the fan working mode.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to select the desired mode:
• AUTO
Temperature controlled with the focus on maintaining highest possible light output.
• STILL
Temperature controlled with the focus on low fan noise (reduced light output when needed).
• Once the correct option shows on the display, press the ENTER button to save it.
LED TEMP
Shows the actual LED temperature.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
JB SYSTEMS
®
The projector follows the instructions instantly, no delay.
The projector imitates the behavior of a halogen lamp (slower reaction time).
7/13
USER MANUAL
LED PAR64FC ZOOM
