JB Systems LED PAR64FC ZOOM Operation Manual page 10

ENGLISH
LOCKING
Used to lock the setup menu against unwanted altering of the settings.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to select the desired mode:
• OFF
The setup menu can be used at any time.
• ON
After a short time the setup menu locks automatically, the display shows LOCKED *****.
Unlock the display by pressing the buttons in this order: UP, DOWN, UP, DOWN, ENTER.
• Once the correct option shows on the display, press the ENTER button to save it.
NO DMX
Used to set how the projector reacts when the DMX-signal suddenly disappears.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to select the desired mode:
• BLACKOUT
• FREEZE:
• Once the correct option shows on the display, press the ENTER button to save it.
Note: as soon as the input detects a DMX-signal, blackout or freeze mode will be cancelled.
DEFAULT
This is your emergency exit if you really messed up the settings: just return to factory settings.
Also 2 user settings can be saved/loaded.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to selected the desired settings:
• FACTORY
• USER1
• USER2
• Press the ENTER button:
• FACTORY was selected: the display shows LOAD
• Press the ENTER button: the display shows ACTION?
• Use ▲/▼buttons to select YES / NO
• Press the ENTER button to confirm.
• USER1 / USER2 was selected:
• Use ▲/▼buttons to select LOAD / SAVE
• Press the ENTER button to confirm: the display shows ACTION?
• Use ▲/▼buttons to select YES / NO
• Press the ENTER button to confirm.
• SAVE was selected: the current settings of the setup menu are saved to memory.
• LOAD was selected: the previously saved settings are loaded.
Default factory settings:
PARAMETER name
DMX Channel mode
SOUND MODE sensitivity
AUTO RUN Chase repeat
EFFECT MODE
CUSTOM Static color
MASTER DIM
WHITE BALANCE
DIM Curve
LED behavior
FANSPEED
Auto Lock Menu
No DMX mode
JB SYSTEMS
®
output turns black while no DMX is detected.
output based on the last valid DMX-signal is kept on the projector.
Defaults factory
6CH
SENS:25
SP=50 R=3
CFADE SP50 F00
WW 2700K
100%
RGBL = 255
SQUARE
HALOGEN
AUTO
OFF
FREEZE
USER defaults 1
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current custom color settings
Current setting in the menu
Current white balance settings
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
8/13
USER MANUAL
USER defaults 2
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current custom color settings
Current setting in the menu
Current white balance settings
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
Current setting in the menu
LED PAR64FC ZOOM
