SLAVE MODE
Used to set the projector as slave in a master/slave setup.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button
SOUND SENS
Used to set sensitivity of the internal microphone, so the projector reacts in the best condition when
in sound controlled mode.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the sensitivity SENS can now be changed
• Use ▲/▼buttons to select the desired sensitivity. (00 = lowest sensitivity, 31=highest sensitivity)
• Press the ENTER button to confirm your settings
AUTO RUN
Used to run all the internal automatic programs automatically.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Use ▲/▼buttons to select the desired SP playback speed from 01 (very slow) to 99 (fast).
• Once the correct value is shown on the display you have to press the ENTER button to confirm.
• Use ▲/▼buttons to select the desired R Repetitions from R01 (1 repetition) to 10.
• Once the correct value is shown on the display, press the ENTER button to save it.
EFF MODE
Used to set the desired effect mode while used as master.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• After 1 second, the last selected effect will start running. The name of the effect is now written on the
display
• Press the ENTER button: the values can be changed
• Use ▲/▼buttons to selected the desired mode:
• COL.CH04
• COL.CH15
• COL.FADE
• Once the desired option is shown on the display you have to press the ENTER button to confirm.
• Use ▲/▼buttons to select the desired SP playback speed from 01 (very slow) to 99 (fast).
• Once the correct value is shown on the display you have to press the ENTER button to confirm.
• Use ▲/▼buttons to select the desired F strobe speed from 00 (NO strobe) to 99 (fast).
• Once the correct value is shown on the display, press the ENTER button to save it.
STATIC
Used to set the desired fixed color while used standalone without controller or as master in a
master/slave configuration : 2 white presets + 6 color presets + 1 custom color.
• Press the MENU button or ▲/▼buttons until the desired function is showing on the display.
• Press the ENTER button: the values can be changed
• Use DOWN and UP buttons to selected the desired color:
• LIME
• BLUE
• CYAN
• GREEN
• YELLOW
• RED
• Color CW
• Color WW
• SET this is a color that can be set by the user. Follow these steps:
• Press the ENTER button: the display shows the value (000-255) for RED. (use ▲/▼buttons)
• Press the ENTER button: the display shows the value (000-255) for GREEN. (use ▲/▼buttons)
• Press the ENTER button: the display shows the value (000-255) for BLUE. (use ▲/▼buttons)
• Press the ENTER button: the display shows the value (000-255) for LIME. (use ▲/▼buttons)
• Press the ENTER button: the display shows the value (001-099) for F (STROBE). (use
▲/▼buttons)
JB SYSTEMS
®
(COLOR CHANGE 4) 4 colors change automatically without fading.
(COLOR CHANGE 15) 15 colors change automatically without fading.
(COLOR FADE) colors change with a nice fading effect.
cold white
warm white
