DPS Telecom NetGuardian 8A User Manual page 7

2
Specifications
Hardware
Dimensions: 16 .9" W x 1.75" H x 5.12" D
Mounting: 19 " or 23 " Rack
Weight: 2.2 lbs (0.978 kg)
Power I nput: -48VDC (-18 to -60 VDC)
-24VDC
3
Current Draw: 60 mA @ 48 VDC
12 0mA @ 24 VDC
Fuse: 3/ 4 Amp GMT Fuse
Audible Interfaces : Alarm Speaker
Visual Interfaces: 8 Front Panel LEDs
6 back LED's
1
Hardware Interfaces : 1 RJ45 10/100BaseT Ethernet
1 RS-232 Serial (or optional RS-485)
1 USB Craft Port
1 RJ-11 D-Wire sensor network (optional)
8 RJ45 (Analog)
1 RJ45 (2x Relay)
1 RJ45 (4x Alarm)
Software
Downloadable Firmware: Yes
Built-in Web I nterface: Yes
Browser Support: IE9, IE10, Firefox.....
Protocols: DCPx, TELNET, HTTP, Email....
SNMP Support: v1, v2c, v3
Note :
1
Valid if hardware option is included.
2
Minimum lengths determined with TTL voltage level alarms. Actual distance may v ary .
3
Current measured at rated voltag e with all controls latched and all alarms trigg ered.
4
See analog section in manual for detailed analog accuracy break down.
* This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
desig ned to provide reasonable protection against harmf ul interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio f requency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
Discrete Alarm Inputs:
2
Discrete Alarm Length:
Analogs:
Input Range:
4
Analog Accuracy:
Control Outputs:
Max Voltage:
Max Current:
Operating Temp:
1
Industrial Operating Temp:
Operating Humidity:
MTBF:
RoHS:
Orde ring Options:
1
D-Wire Sensor Support:
Ping Alarms:
OS Support:
8 (reversible)
000Ft. (0 0m) per Alarm
8 (plus 2 for power)
-92 to +92 VDC or 4 to 2 0mA
± 1% of Analog Range
2 Relays
60 VDC/12 0 VAC
1A AC/DC
32° to 140°F (0° to 60°C)
-22° to 1 58°F (-30° to 70°C)
0% to 95% non-condensing
60 Years
RoHS 5 Approved
D-Wire
Most variants (up to 16 including internal
temp)
32
Windows 95, 98, NT, ME, XP, 2000, Vista, 7
32/64bit
3
