Summary of Contents for Roger ME-40
- Page 1 Roger Access Control System Metal Enclosure ME-40 Operating Manual Product version: v1.1 Firmware version: – Document version: Rev. C...
- Page 2 Optionally, the door can be equipped with a key lock. The ME-40 is made of a metal sheet with an anthracite grey powder coating. Enclosure offers space for 17Ah battery. Originally, the enclosure was designed to be equipped with 24VDC/50W power supply module, however it is not installed in factory new ME-40 enclosure.
- Page 3 Fig. 2 Internal view of ME-40 enclosure: A: Mains Supply Terminal Blocks; B: Main Supply Entry Hole with Protective Sleave; C: Low Voltage Connection Holes; D: Tamper Contact; E: Power Supply Module;...
- Page 4 ME-40 Operating Manual 2024-09-05 Fig. 3 Cable fixing method Fig. 4 Forming a cable entry hole in the bottom or top wall of the enclosure 3. S PECIFICATION Parameter Value Nominal Power Supply 230VAC Nominal Power (*) Nominal Output Voltage (*)
- Page 5 Weight of the equipment is specified in the document. Contact: Roger Sp. z o. o. Sp. k. 82-400 Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133...
