- Page 1 Roger Access Control System MCT82M AND MCT84M SERIES OPERATING MANUAL QUADRUS series Firmware: v1.1.2 and higher Hardware version: v1.0 Document version: Rev. B This document refers to the following products: MCT82M, MCT82M-BK, MCT82M-IO, MCT82M-IOBK, MCT84M, MCT84M-BK Roger Sp. z o.o. sp. k. 2017...
-
Page 2: Table Of Contents
CONTENTS Functional description .................... 1 Features ......................1 RFID transponders ....................1 Card code ......................1 CSN section..................... 2 PCN section ..................... 2 RCN number ....................4 Inputs ....................... 6 Input types ..................... 6 NO type ......................6 NC type ......................6 EOL/NO type .................... -
Page 3: Functional Description
Communication with the controller is achieved through an RS485 bus and EPSO 3 (Roger) protocol. Factory new reader is set to ID=100 RS485 address. Programming of address is made by means of RogerVDM program (Windows) or manually (see: Manual programming of address). -
Page 4: Csn Section
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 + PCN). CSN section is a fragment of RCN which has been taken from CSN number. PCN section is a fragment of RCN which has been taken from programmable data sectors. PCN number can be protected from any modifications and unauthorized reading attempts by its encryption. - Page 5 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 PCN is read from the indicated sector and block of a card. AID number (Application ID) is ignored. PCN is read from indicated block in the first identified sector, which has been marked by two-byte AID number. In some cases many sectors may be marked by indicated AID, so it is possible to read a random value from the block.
-
Page 6: Rcn Number
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 read PCN code read from block: Example Settings: FBP=2, LBP=10, Format=ASCII HEX. The form of data stored on card block is presented below: Pos. ASCII ‘0’ ‘1’ ‘2’ ‘3’ ‘4’ ‘5’ ‘6’ ‘7’ ‘8’... - Page 7 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 CSN section PCN section Depending on output format RCN number may be transmitted to controller in different ways. Few examples of transmitting options of the same RCN=C4C5C6C7223344h number by readers which work in various output formats are presented below. Example RCN number which is sent by reader working on Number 64 bit card number data type:...
-
Page 8: Inputs
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 NPUTS MCT82M series readers with IO option (e.g. MCT82M-IO, MCT82M-IOBK) are equipped in three parametric inputs. During the low level configuration it is possible to define parameters specifying operation method of inputs. The following parameters are available to set for inputs: ... -
Page 9: Eol/No Type
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 EOL/NO TYPE Input of such type can be in normal, triggered or sabotage (tamper) state. In normal state C contacts are opened. Triggering of input is caused by closing the C contact. The changing of R resistor resistance in normal state indicates a sabotage (tamper) Tamp... -
Page 10: 2Eol/Nc Type
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 2EOL/NC TYPE Input of such type allows to recognize a normal, triggered, sabotage and damage state. In normal state C and C contacts are closed. Triggering of input is caused by Tamp opening the C contact. -
Page 11: 3Eol/Nc Type
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 3EOL/NC TYPE Input of such type allows to recognize following states: normal, triggered, masking, triggered with masking, sabotage and damage. In normal state C and C Tamp contacts are closed. Triggering of input is caused by opening the C contact. -
Page 12: Name Or Comment
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 NAME OR COMMENT Name or comment parameter allows to associate any text (description) with an input, which will be visible in VISO software, making easier to identify and operate the system. UTPUTS MCT12M series readers with IO option (e.g. MCT12M-IO, MCT12M-DIO, MCT12M-IOBK, MCT12M-DIOBK) are equipped in two transistor outputs and one relay output. -
Page 13: Reader Configuration
Programming). ROGRAMMING FROM PC To perform this method reader has to be connected to PC via RUD-1 interface and programmed by means of RogerVDM software (available on www.roger.pl). Programming procedure: 1. Connect reader to RUD-1 interface according to Fig. 1. -
Page 14: Configuration Parameters
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 Fig. 1 Reader connection method to RUD-1 interface ONFIGURATION PARAMETERS Table 1: Configuration parameters description Parameter name Available values Description Communication options 1: RS485A (range of 100-115) Parameter sets device RS485 bus RS485 address address. - Page 15 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 0 - Off Keypad backlight When option is set keypad dimming backlight is switched off for a while 1 - On whenever card is read or key pressed. 0 - Off LED SYSTEM flash When option is set LED SYSTEM after card read generates single flash whenever...
- Page 16 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 0 - Normal polarity OUT1 Output polarity determines electric state of output in normal (not 1 - Reverse polarity triggered) mode. OUT2 as above as above REL1 as above as above Acoustic signalisation Buzzer loudness 0..100% Defines buzzer loudness level.
- Page 17 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 [F1] key press as above as above type [F2] key press as above as above type Advanced settings 0 – No Stop card/PIN When option is active reader stops reading when card/PIN reading until previous 1 –...
-
Page 18: Manual Programming Of Address
Key type Specifies key type used to encrypt data stored on the card. 1 - B key type 2 - Roger key type (RSS) 000000000000-FFFFFFFFFFFF 6 bytes key used to encrypt data stored on the card. ANUAL PROGRAMMING OF ADDRESS This procedure is intended to set a new RS485 bus address of the reader while maintaining the rest of configuration settings. -
Page 19: Memory Reset
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 3. Read card 1 time and wait for double beep. 4. Wait until reader restarts with a new address. EMORY ESET Memory reset procedure deletes all configuration settings and restores factory defaults with RS485 address set to 100. To perform memory reset follow these steps: 1. -
Page 20: Firmware Upgrade
F I R M W A R E U P G R A D E Firmware can be upgraded by means of RogerVDM software and RUD-1 communication interface. The file with latest firmware is available at www.roger.pl Firmware upgrade procedure: 1. Connect reader to RUD-1 interface according to Fig. 2. -
Page 21: Installation Guidelines
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 I N S T A L L A T I O N G U I D E L I N E S 1. Reader should be mounted on a vertical piece of supporting structure, usually wall, away from sources of heat and moisture. -
Page 22: Specification And Drawings
Nominal reading range was declared for Roger reference ISO card placed in parallel to the front surface of the reader in such a way that card center is aligned with vertical axe of the reader and located approx. -
Page 23: Ordering
MCT82M-BK 13.56 MHz ISO/IEC 14443A/MIFARE® indoor reader, screw terminals, QUADRUS series MCT82M-IO 13.56 MHz ISO/IEC 14443A/MIFARE® indoor reader, built-in inputs/outputs, sensor keypad, screw terminals, QUADRUS series MCT82M-IOBK 13.56 MHz ISO/IEC 14443A/MIFARE® indoor reader, built-in inputs/outputs, screw terminals, QUADRUS series MCT84M 13.56 MHz ISO/IEC 14443A/MIFARE®... -
Page 24: Drawings
MCT82M and MCT84M series Operating Manual.doc 2018-05-11 RAWINGS Fig. 3 Connection terminals and programming jumpers Fig. 4 Location of latches Page 22... - Page 25 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 Fig. 5 Dimensions and location of Tamper lever Page 23...
- Page 26 MCT82M and MCT84M series Operating Manual.doc 2018-05-11 Fig.6 Readers and modules connection to MC16 Page 24...
- Page 27 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp. k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Faks: +48 55 272 0133 Tech.
