- Page 1 Roger Access Control System MCT86M-IO-HR-CH Operating Manual Product version: 1.0 Firmware version: 1.1.18 or newer Document version: Rev. B...
-
Page 2: Design And Application
Room, Cafeteria and Do Not Disturb by means of touch function keys. The device is connected to access controller through RS485 interface. Note: The application of RACS 5 system in hotels is explained in AN033 application note which is available at www.roger.pl. Characteristics ... - Page 3 MCT86M-IO-CH-HR Operating Manual 09.07.2020 Fig. 1 MCT supply from MC16 access controller Fig. 2 MCT supply from dedicated power supply unit RS485 bus The communication with MC16 access controller is provided with RS485 bus which can encompass up to 16 devices of RACS 5 system, each with unique address in range of 100-115. The bus topology can be freely arranged as star, tree or any combination of them except for loop.
-
Page 4: Function Keys
MCT86M-IO-CH-HR Operating Manual 09.07.2020 Function keys The terminal is equipped with four touch function keys. They are mainly dedicated to control such hotel signalisations as Luggage Service, Make Up Room, Cafeteria, Do Not Disturb but they can be alternatively assigned with other functions within high level configuration (VISO). Within low level configuration (RogerVDM) of the terminal it is possible configure if terminal distinguishes short and long key pressings. - Page 5 MCT86M-IO-CH-HR Operating Manual 09.07.2020 Table 1. Input types NO input NC input NO input can be in normal or in triggered state. In NC input can be in normal or in triggered state. In normal state C contacts are opened. Input normal state C contacts are closed.
-
Page 6: Tamper Detector
AN024 application note which is available at www.roger.pl. The technical characteristics of the device are guaranteed for RFID cards supplied by Roger. Cards from other sources may be used, but they are not covered by the manufactures warranty. Before deciding to use specific Roger products with third-party contactless cards, it is recommended to conduct tests that will confirm satisfactory operation with the specific Roger device and software in which it operates. - Page 7 MCT86M-IO-CH-HR Operating Manual 09.07.2020 Fig. 4 MCT86-IO-CH-HR installation 7/15...
-
Page 8: Operation Scenario
MCT86M-IO-CH-HR Operating Manual 09.07.2020 Fig. 5 Programming jumpers Installation guidelines The terminal should be mounted on a vertical structure (wall) away from sources of heat and moisture. Front panel should be attached in such way as the tamper detector (fig. 5) would firmly press the back panel. -
Page 9: Low Level Configuration (Rogervdm)
MCT86M-IO-CH-HR Operating Manual 09.07.2020 Fig. 6 Typical connection diagram for the terminal and MC16 access controller 4. C ONFIGURATION Low level configuration (RogerVDM) The purpose of low level configuration is to prepare device for operation in RACS 5 system. Programming procedure with RogerVDM software: 1. - Page 10 MCT86M-IO-CH-HR Operating Manual 09.07.2020 Fig. 7 Connection of MCT terminal to RUD-1 interface (low level configuration) Table 4. List of low level parameters Communication settings RS485 address Parameter defines device address on RS485 bus. Range: 100-115. Default value: 100. RS485 communication timeout [s] Parameter defines delay after which device will signal lost communication with controller by means of its LED indicators.
- Page 11 MCT86M-IO-CH-HR Operating Manual 09.07.2020 press. Default value: [1]: Short press only. Advanced settings Stop card/PIN reading when Parameter enables to reject card/PIN reading by device till previous buffer full card/PIN is transmitted to controller. Range: [0]: No, [1]: Yes. Default value: [0]: No.
- Page 12 0-31 and 0-14 for sectors 32-39. Default value: 0. Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B, [2]: Roger. Default value: [0]: A. Parameter defines 6 bytes (12 HEX digits) key for accessing sector where PCN is stored.
-
Page 13: Manual Addressing Procedure
MC16 access controller and it depends on applied scenario of operation. The example of access control system configuration is given in AN006 application note while hotel system configuration is explained in AN033 application note. Both notes are available at www.roger.pl. 5. F IRMWARE UPDATE The update requires connection of device to computer with RUD-1 interface (fig. -
Page 14: Specification
MCT86M-IO-CH-HR Operating Manual 09.07.2020 7. When the update is finished, remove FDM jumper and restart the device. Fig. 8 Connection of MCT terminal to RUD-1 interface (firmware update) 6. S PECIFICATION Table 5. Specification Supply voltage Nominal 12VDC, min./max. range 10-15VDC Current consumption ~60 mA... - Page 15 MCT86M-IO-CH-HR Operating Manual 09.07.2020 signalling function key panel. RUD-1 Portable USB-RS485 communication interface dedicated to ROGER access control devices. 8. P RODUCT HISTORY Table 7. Product history Version Date Description MCT86M-IO-CH-HR v1.0 06/2018 The first commercial version of product This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health.
