- Page 1 Roger Access Control System MCT84M-BK-QB Operating Manual Product version: 1.0 Firmware version: 1.0.10.216 Document version: Rev.B...
-
Page 2: Design And Application
1. D ESIGN AND APPLICATION The MCT84M-BK-QB is an identification terminal dedicated to RACS 5 access control system. Optionally, reader can be configured to open communication protocol and used in other scenarios (e.g. in automation systems). Users can be identified by use of QR code, BLE/NFC mobile ID or proximity card. Reader supports encrypted QR codes that are compatible with Roger standard or non-encrypted codes. - Page 3 MCT84M-BK-QB Operating Manual.doc 19.10.2023 Fig. 1 MCT supply from MC16 access controller Fig. 2 MCT supply from dedicated power supply unit RS485 bus The communication method with MC16 access controller is provided with RS485 bus which can encompass up to 16 devices of RACS 5 system, each with unique address in range of 100-115. The bus topology can be freely arranged as star, tree or any combination of them except for loop.
-
Page 4: Led Indicators
MCT84M-BK-QB Operating Manual.doc 19.10.2023 LED indicators Terminals are equipped with three LED indicators which are used to signal integral functions and they can be additionally programmed with other available functions within high level configuration (VISO). Table 3. LED indicators Indicator... - Page 5 Communication Encryption Key, and in the case of Bluetooth, additionally verify whether the BLE parameter is enabled. Install the Roger Mobile Key (RMK) application on the mobile device and set the same parameters as in the terminal. Create a key (authentication factor) in RMK by defining its type and number and then create the same authentication factor in the VISO program (fig.
- Page 6 NFC/BLE Communication Encryption Key as part of the low-level configuration of the device (see point 4). Install the Roger Mobile Key (RMK) application on the mobile device and set the same parameters as in the terminal. Create a new identifier in RMK by defining its type as QR and value (fig. 6) Then create the same authentication factor in VISO (fig.
-
Page 7: Installation
MCT84M-BK-QB Operating Manual.doc 19.10.2023 Fig. 6 Defining a QR code in the Roger Mobile Key app. Fig. 7 Authentication factor type for the barcode in the VISO program 2. I NSTALLATION Table 3. Wires Name Wire colour Description 12VDC power supply... - Page 8 MCT84M-BK-QB Operating Manual.doc 19.10.2023 8/17...
-
Page 9: Operation Scenarios
19.10.2023 Fig. 8 MCT84M-BK-QB installation Note: MCT84M-BK-QB enclosure consists of front panel and back panel. New device is assembled with a standard back panel, but additional free of charge, extended back panel is included. This panel can be used when connection cable has to be hidden and no flush mounting box is available. -
Page 10: Low Level Configuration (Rogervdm)
MCT84M-BK-QB Operating Manual.doc 19.10.2023 4. C ONFIGURATION The purpose of low level configuration is to prepare device for operation in RACS 5 system. In case of RACS 5 v1 system the address of device must be configured by means of RogerVDM software or by manual addressing before connection to MC16 controller. - Page 11 NFC authentication factor class Parameter defines acceptable type of keys (authentication factors) created in Roger Mobile Key app for NFC communication. UCE means lower security and quicker identification while REK means higher security and slower identification. It is necessary to apply classes in RMK which are acceptable for terminal.
- Page 12 MCT84M-BK-QB Operating Manual.doc 19.10.2023 AF type Parameter defines authentication factor type returned by terminal. Default value: [0010]: Number 40bits. Long card read time [s] Parameter defines long card read time. When set to 0 then long read is disabled. Range: 0-64. Default value: 0.
- Page 13 MCT84M-BK-QB Operating Manual.doc 19.10.2023 CDI1 Parameter defines any text or comment which corresponds to the device/object. It is later displayed in VISO program or Roger Mobile Key app. IN1 (Tamper) Parameter defines any text or comment which corresponds to the device/object.
-
Page 14: Manual Addressing
MCT84M-BK-QB Operating Manual.doc 19.10.2023 Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B. Default value: [0]: A. Parameter defines access key for Desfire file with PCN. 3-KTDES key is 16 bytes (32 HEX digits), TDES and AES keys are 16 bytes (32 HEX digits). -
Page 15: Memory Reset
The purpose of high level configuration is to define logical functioning of the terminal which communicates with the MC16 access controller and it depends on applied scenario of operation. The example of access control system configuration is given in AN006 application note which is available at www.roger.pl. 5. F IRMWARE UPDATE The firmware of device can be changed to newer or older version. -
Page 16: Ordering Information
130 x 45 x 22 mm Weight ~100g Certificates 7. O RDERING INFORMATION Table 8. Ordering information MCT84M-BK-QB Access Terminal RUD-1 Portable USB-RS485 communication interface dedicated to ROGER access control devices 8. P RODUCT HISTORY Table 9. Product history Version Date Description MCT84M-BK-QB 07/2022 The first commercial version of product v1.0... - Page 17 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
