Summary of Contents for Roger MCT82M-IO-CH

  • Page 1 Roger Access Control System MCT82M-IO-CH Operating Manual Product version: 1.0 Document version: Rev. B...
  • Page 2: Functional Description

    The terminal is equipped with card holder, bicolour LED line and onboard I/Os including relay output. The MCT82M-IO-CH enables continuous monitoring of card in the holder and reporting its status to the access controller. Both, card inserting and removing can trigger individually programmed actions in the system if adequate authorizations are assigned to the card.
  • Page 3: Output Control By Card In The Holder

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 It represents part of the device which offers text display. It represents part of the device which offers power supply output. It represents part of the device which offers clock and calendar. Each object is presented in system management software (VISO program, section Hardware Resources) and can be used to any system function suitable for its type.
  • Page 4: Led Light Line And Buzzer Output

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 Logical object Access Point collects data from the Access Terminals and based on the received data recognises user who logs in at the reader. Once the user is recognised, Access Point verifies user’s authorisations and it can send the activation request to Automation Node when card is inserted and send deactivation request to Automation Node when card is removed.
  • Page 5: Tamper Input

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 TAMPER input Reader is equipped with contact which can detect both opening of the enclosure and enclosure detachment from the mounting surface (wall). The status of the contact represented by TAMPER input is continuously monitored by reader’s electronic module and reported to the access controller. During system configuration the TAMPER input can be assigned to TAMPER function or another (when required).
  • Page 6: Input Types

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 device till previous card/PIN is transmitted to controller. Range: [0]: No, [1]: Yes. Default value: [0]: No. Card/PIN buffer timeout [s] Parameter defines time for card/PIN storing in device buffer. When the time elapses the buffer is cleared even if card/PIN is not transmitted to controller.
  • Page 7 32-39. Default value: 0. Key type Parameter defines key type used to access sector with PCN. Range: [0]: A, [1]: B, [2]: Roger. Default value: [0]: A. Parameter defines 6 bytes (12 HEX digits) key for accessing sector where PCN is stored.
  • Page 8: Manual Address Programming

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 Sector type Parameter defines sector type with programmable number (PCN). If the option [0]:None is selected then card returned number (RCN) will include only CSN and PCN will be discarded. Range: [0]: None, [1]: Desfire file. Default value: [0]: None.
  • Page 9: Programming From Computer

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 Note: Manual address programming enables configuration of new RS485 address with all other settings unchanged. Example Programming of ID=103 address with multiple card readings:  Disconnect power supply from the reader  Disconnect wires from RS485 A and B lines (if applicable) ...
  • Page 10: Memory Reset

    Remove jumper from MEM contacts and restart the reader. Firmware update The update requires connection of reader to computer with RUD-1 interface and starting RogerVDM software. The latest firmware file is available at www.roger.pl. Firmware update procedure:  Connect reader to the RUD-1 interface according to fig. 4 ...
  • Page 11: Connection To Rs485 Bus And Power Supply

    MCT82M-IO-CH Operating Manual.doc 2018-09-26  Select device type, serial port with RUD-1 interface and path to firmware file (*.hex). Update  Click  When the update is finished, remove jumper from FDM contacts  Restart the reader (switch power supply off and on or short RST contacts for a moment).
  • Page 12: Control Of 230Vac Power Supply

    Fig. 6 MCT supply from access controller Control of 230VAC power supply MCT82M-IO-CH can be operated as a switch controlling the 230VAC power supply of a room, machine or device depending on the presence of authorized card in the holder. External relay/contactor for 230VAC must be applied in such scenario.
  • Page 13: Installation

    MCT82M-IO-CH Operating Manual.doc 2018-09-26 Fig. 7 Example of 230VAC power supply by card in holder Installation 1. Install the reader on the flat surface (wall), in a place free from strong electromagnetic interferences and in a distance from metal objects.
  • Page 14 MCT82M-IO-CH Operating Manual.doc 2018-09-26 Fig. 8 MCT82M-IO-CH surface mounting 14/17...
  • Page 15 MCT82M-IO-CH Operating Manual.doc 2018-09-26 Fig. 9 MCT82M-IO-CH-F flush mounting 15/17...
  • Page 16 MCT82M-IO-CH Operating Manual.doc 2018-09-26 Table 5. Specification Parameter Value Supply voltage Nominal 12VDC, min./max. range 10-15VDC Current consumption (average) ~60 mA Inputs Three parametric inputs (IN1..IN3) internally connected to the power supply plus through a 5.6kΩ resistor. Approx. 3.5V triggering level for NO and NC inputs.
  • Page 17 Recycling helps to reduce the consumption of raw materials, thus protecting the environment. Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp. k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
