2.5 Video
Controller
Intel® UHD Graphics
Display Interface
•
Support
•
•
•
2.6 Audio
Audio Codec
Realtek ALC897
Interfaces
1x Line-out, 1x Mic-in connector
2.7 LAN
Controller
1x Intel® i226-V with 10/100/1000/2500 Mbps
1x Intel® i219-LM with 10/100/1000 Mbps, supports vPro
Interface
RJ45 connectors
2.8 Trusted Platform Module (TPM)
TPM 2.0 Infineon
2.9 Power Specification
ATX PWR (24+4-pin) and +12V DC-In co-design
Input PWR
AT/ATX Supported
- AT: Directly PWR on as power input ready
Power On
- ATX: Press button to PWR on after power input ready
6
1x HDMI 2.0b, max resolution up to 4096x2160@60Hz
1x HDMI 1.4b, max resolution up to 4096x2160@30Hz
1x DP 1.4a, DP++, max resolution up to 4096x2160@60Hz
1x LVDS, supports dual channel 24-bit, max resolution up to 1920x1200@60Hz (Connector
shared with eDP)
SLB9670XQ2.0
Specifications
