Kichler Lighting Sutter Place Premier Instruction Manual page 12

11
13. TROUBLESHOOTING
Problem Solution
Fan will not start. 1. Check that all fuses or circuit breakers are installed or in the ON position.
2. Check all electrical connections to insure proper contact. CAUTION: Make
Fan sounds noisy. 1. Make sure all motor housing screws are snug.
2. Make sure the screws that attach the fan blade bracket to the motor hub is
3. Make sure wire nut connections are not rubbing against each other or the
4. Allow a 24-hour "breaking-in" period. Most noise associated with a new fan
5. If using an optional light kit, make sure the screws securing the glassware
6. Some fan motors are sensitive to signals from solid-state variable speed
7. Make sure the upper canopy is a short distance from the ceiling. It should not
Fan wobble. 1. Check that all blade and blade arm screws are secure.
2. Most fan wobbling problems are caused when blade levels are unequal.
3. Use the enclosed Blade Balancing Kit if the blade wobble is still noticeable.
4. If the blade wobble is still noticeable, interchanging two adjacent (side by
WARNING: TO REDUCE THE RISK OF PERSONAL INJURY AND TO
INUSRE THE PROPER OPERATION OF YOUR CEILING FAN. NEVER
ATTACH THE BLADE ASSEMBLIES UNTIL THE CEILING FAN HAS BEEN
MOUNTING ON THE CEILING. DO NOT BEND THE BLADE ARMS WHILE
INSTALLING, BALANCING OR CLEANING THE FAN. DO NOT INSERT
FOREIGN OBJECTS BETWEEN ROTATING FAN BLADES.
14. SPECIFICATIONS
Fan Size Speed
Low
52"
Medium
High
These are approximate measures. They do not include Amps and Wattage used by the light kit.
sure the main power is OFF when checking any electrical connection.
tight.
interior wall of the switch housing.
CAUTION: Make sure main power is off.
disappear during this time.
are tight. Make sure the light bulbs are not touching any other component.
controls. If you have installed this type of control, choose and install another
type of control.
touch the ceiling.
Check this level by selecting a point on the ceiling above the tip of one of the
blades. Measure this distance. Rotate the fan until the next blade is
positioned for measurement. Repeat for each blade. The distance deviation
should be equal within 1/8".
side) blades can redistribute the weight and possibly result in smoother
operation.
Volts Amps Watts
120 0.49 59.0
0.35 28.0
120
120
0.20 9.50
RPM CFM CFM/W
160 4500 76
113 3196 114
62 1602 169
N.W. G.W. C.F.
8.46 9.46 1.93'
kgs kgs
