- Page 1 Szeplo II 300300,300301,300302 A Kichler Decor ceiling fan ® ™ Includes wall mount control system Kichler Lighting ® 7711 East Pleasant Valley Road P.O. Box 318010 Instruction Manual Cleveland, Ohio 44131-8010 Customer Service 866.558.5706 8:30 AM to 5:00 PM EST,...
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the blades. electricity has been turned off at the circuit breaker or fuse box before beginning. 9. To avoid personal injury or damage to the fan and other items, be cautious when 2. -
Page 3: Tools And Materials Required
Szeplo II 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents . You should have the following items: Mounting bracket Ball / downrod assembly C. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing ETL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building structure. Use appropriate fasteners and Outlet box building materials. -
Page 5: Hanging The Fan
Szeplo II 5. HANGING THE FAN ETL Listed Outlet Box REMEMBER to turn off the power before you begin installation. This is necessary for your Ceiling Mounting Bracket safety and also the proper programming of the Flat Washer control system. -
Page 6: Installation Of Safety Support
Step 5. Now lift the motor body into position and place the hanger ball into the hanger bracket. Hanger Ball Rotate until the "Check Tab" has dropped into the "Registration Slot " and seats firmly. ( Fig. 9) Check Tab Registration Slot The entire motor body should not rotate is this is done correctly. -
Page 7: How To Wire Your Ceiling Fan
Szeplo II 7. HOW TO WIRE YOUR CEILING FAN If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electricial. Black Wire Warning: To avoid possible electrical shock, be... -
Page 8: Attaching The Fan Blades
Step 3. Securely attach and tighten the canopy trim ring over the shoulder screws in the mounting bracket utilizing the keyslot twist-lock feature. Canopy Trim Ring (Fig. 16) Fig. 16 9. ATTACHING THE FAN BLADES Blade Screw Washer NOTE: Before continuing, make sure the power is disconnected by turning off the circuit breaker of removing the fuse at the circuit box. -
Page 9: Installing The Mounting Plate
Szeplo II 10. INSTALLING THE MOUNTING PLATE Step 1. Remove one of the three screws and loosen the other two (do not remove). Place the two slot holes on the switch housing over the 2 screws previously loosened from the mounting Mounting Plate ring. -
Page 10: Wall Control Installation
Step 3. Secure the glass shade to switch housing by twisting in a clockwise direction. Do not over-tighten. (Fig. 22) Switch Housing Glass Shade Fig. 22 Step 4. If you want to install the steel cap and not the light kit. Assemble the steel cap to the Switch Housing switch housing by twisting in a clockwise direction. -
Page 11: Pairing Procedures
Szeplo II Step 2. Before installing the wall control, place it in "OFF" mode by press the button. (higher than faceplate). Step 3. Connect one black wire of wall control to the "hot" wire (house source). Securely connect wires with wire connectors supplied. (Fig. 25) Step 4. -
Page 12: Using Your Ceiling Fan
14. USING YOUR CEILING FAN Press the" "button once to turn ON (or OFF) the fan. (Fig. 26) To set the desired fan speed, press and hold the" " button to decrease and increase the speed. (Fig. 26) Indication Light Airflow Direction (Power) To turn the light on and off, press and release the... -
Page 13: Specifications
16. FCC WARNNING: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifictions not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
