  • Page 1 Intelligent Power Module FIK-5496 Manual Document LS10253-001FK-E 5/25/2022 Rev: P/N LS10253-001FK-E:B • ECN 00003636...
  • Page 2 Heat detectors are designed to Limit-F-2020 protect property, not life. FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 3 Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation. ©2022. All rights reserved. Unauthorized use of this document is strictly prohibited. FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 4 Electrical and electronic equipment contains materials, parts and substances, which can be dangerous to the environment and harmful to human health if the waste of electrical and electronic equipment (WEEE) is not disposed of correctly. FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 5 3.6: Connecting the FIK-5496 to the FACP................................11 3.6.1: Setting the Device ID....................................12 3.7: Notification Appliance Wiring..................................12 3.7.1: Class A Supervised Wiring...................................12 3.7.2: Class B Supervised Wiring...................................13 3.7.3: Releasing Operations ....................................13 3.7.4: Auxiliary Power Configuration ................................14 FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 6 The FIK-5496 is capable of performing single or dual interlocking operations for pre-action and deluge releasing systems. Refer to the FACP Installation Manual. The FIK-5496 has four output circuits that can be configured as notification or auxiliary power circuits. Outputs are rated 3.0 A (6.0 A total for each FIK-5496).
  • Page 7 Do not mount in areas with humidity-generating equipment (such as dryers, production machinery). When the user selects a location to mount the FIK-5496, the unit should be mounted where it will NOT be exposed to temperatures outside the range of 32°F-120°F (0°C-49°C) or humidity outside the range of 10%-93% at 86°F (30°C) non-condensing.
  • Page 8 2.4.2 Maximum Battery Standby Load Table 2.1 shows the maximum battery standby load for the FIK-5496 based on 24 and 60 hours of standby. The numbers below have a built in 20% derating factor for the battery amp-hour capacity. The standby load calculations of line J in the Current Draw Calculation Worksheet (Table 2.2) must be less than the number shown in Table 2.1 for the battery size used and standby hours required.
  • Page 9 Fike Addressable FACP Installation Manuals can be found on Fike’s website at www.fike.com. 3.1 FIK-5496 Board and Terminal Strip Description Figure 3.1 shows the FIK-5496 circuit board including the location of terminals and the DIP switch for setting the module ID. AC power...
  • Page 10 H 4 – H 4+ H 3 – H 3 + H 2 – H 2 + H 1 – H 1 + S – to NACs battery battery Figure 3.2 Wire Routing FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 11 3.5 Battery Connection The FIK-5496 battery charge capacity is 7.0 AH - 35.0 AH. Use 12V batteries of the same AH rating. It is recommended that you replace batteries every five years. Determine the correct AH rating per your current load calculation (see Table 2.2 on page 8).
  • Page 12 3.6.1 Setting the Device ID All SBUS modules in the system must have a unique number (1-31) to identify them to the FACP. Use the DIP switch on the FIK-5496 board to set the module ID number. Figure 3.1 shows the location of the DIP switch on the board. Figure 3.6 below shows DIP switch settings and the corresponding module ID numbers.
  • Page 13 3.7.2 Class B Supervised Wiring Figure 3.8 shows how to wire for Class B output supervision. Use in/out wiring methods for proper supervision. Refer to the Fike Device Compatibility Document for notification appliances that must be used with the FIK-5496.
  • Page 14 If extra power circuits are needed, a UL 864-listed, regulated, power-limited power supply with Class A aux power output must be used. Sounder Sync Power Sounder sync power continuously outputs the System Sensor synchronization pattern and it is intended for use with the B200S Series sounder bases. FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 15 FIK-5496 Intelligent Power Module Manual — P/N LS10253-001FK-E:B 5/25/2022...
  • Page 16 Fike World Headquarters 704 SW 10th Street Blue Springs, Missouri 64015 USA Tel: +001 816-229-3405 Toll Free (US Only): 1-800-YES-FIKE (1-800-937-3453) www.Fike.com For a list of contact information for Fike offices around the world, visit the Global Locations section of Fike.com...
