INSTALLATION INSTRUCTIONS
55-043 Relay Module
SPECIFICATIONS
Normal Operating Voltage:
Standby Current:
Alarm Current:
Short Circuit Current
Dry Control Input:
Maximum Resistance
Dry Contact Input:
Temperature Range:
Humidity:
Dimensions:
Accessories:
CURRENT RATING
3A
2A
1A
0.5A
0.9A
0.7A
NOTE: This module is not approved for use in the European Union, at or above 50VAC or 70VDC.
BEFORE INSTALLING
This information is included as a quick reference installation
guide. Refer to the appropriate control panel installation manual
for detailed system information. If the modules will be installed
in an existing operational system, inform the operator and local
authority that the system will be temporarily out of service.
NOTICE: This manual should be left with the owner/user of this
equipment.
GENERAL DESCRIPTION
Relay Module, Model 55-043, is to be designed for use in acti-
vation of the types of products that are generally connected to
an intelligent fire alarm system. It provides two sets of form C
contacts that switch together (one DPDT relay). There is also an
input that is capable of monitoring a dry set of contacts for open
or closed conditions.
COMPATIBILITY REQUIREMENTS
To ensure proper operation, this module shall be connected to a
listed compatible control panel.
D500-73-00
15 to 30 VDC
500 µA max. average (continuous broadcasts)
2.0 mA (red LED on)
30 µA max. Avg. (5 VDC)
100 Ω
32°F to 120°F (0°C to 49°C)
10 to 93% RH Noncondensing
4.17ʺH × 4.26ʺW × 1.22ʺD
(106mm H × 108mm W × 31mm D)
Wall cover plate (included)
SMB500 Surface Mount Electrical Box
EA-CB Control Module Barrier
MAXIMUM VOLTAGE
30 VDC
30 VDC
30 VDC
30 VDC
70.7 VAC
70.7 VAC
704 South 10th Street, Blue Springs, MO 64015
LOAD DESCRIPTION
RESISTIVE
RESISTIVE
INDUCTIVE (L/R = 2 ms)
INDUCTIVE (L/R = 5 ms)
RESISTIVE
INDUCTIVE (PF = 0.35)
MOUNTING
The module mounts directly to 4ʺ square electrical boxes. The box
must have a minimum depth of 2
with the arrow facing upward for proper operation of the IR pro-
gramming tool. Surface mounted electrical boxes (SMB500) are
available from Fike.
1
(816) 229-3405
www.fike.com
APPLICATION
NON-CODED
CODED
CODED
CODED
NON-CODED
NON-CODED
⁄
ʺ. Modules must be mounted
1
8
LED
INDICAT OR
IR
RECEIVER
C0166-00
I56-2462-02
