FIKE CORPORATION
704 SW 10th Street
Blue Springs, MO 64015
www.fike.com
1 Description
The Fike Series, Emergency Communication System uses the FIK-NVCM (Network Voice Control Module) and the Fike Series
Fire, Alarm Control Panels use the FIK-NIC (Network Interface Card). The network modules support the following fiber-option
modules that convert wire to fire.
•
FIK-FML (Fiber-Optic Multi-Mode, Receiver)
1.1 FIK-FML (Fiber-Optic Multi-Mode, Receiver)
The FIK-FML is a fiber module that is used as one channel to transmit or receive communications with the FIK-NVCM
(Network Voice Control Module) or FIK-NIC (Network Interface Card). It allows the multi-mode fiber to network between the
FIK-FML module boards. Figure 1 shows the FIK-FML fiber module.
1.2 FIK-FSL (Fiber-Optic Single-Mode, Transmitter)
The FIK-FSL is a fiber module that is used as one channel to transmit or receive communications with the FIK-NVCM
(Network Voice Control Module) or FIK-NIC (Network Interface Card). It allows the single-mode fiber to network between the
FIK-FSL module boards. Figure 2 shows the FIK-FSL fiber module.
Table 1 lists the models that are assigned to the FIK-NVCM and FIK-NIC.
2 FIK-FML/FIK-FSL Specifications
Table 2 lists the FIK-FML multi-mode fiber-optic and the FIK-FSL single-mode fiber-optic modules, digital audio ports
specifications.
Installation
Specifications
Type of Connector:
Maximum Attenuation: 8 dbB for multi-mode with 62.5/12 5 micrometer cable
Current Draw:
Standby Current:
Alarm Current:
Environment Rating:
Relative Humidity:
Figure 1
Figure 2
FIK-NVCM
FCP-2100ECS
FCP-300ECS
Table 1 Network Voice and Interface Card Modules
FIK-FML
Type ST
@ 200 µ.
0.053 A
0.053 A
32° to 120°F (0° to 49°C), 0% to 93%
Non-condensing at 90°F (30°C)
Table 2 FIK-FML Specifications
FIK-FML/FIK-FSL Fiber-Option Modules
Product Installation Document
PN LS10178-002FK-E:A 03/04/2021 ECN: 151526
•
FIK-FSL (Fiber-Optic Single-Mode Transmitter)
FIK-FML Fiber Module
FIK-FSL Fiber Module
FIK-NIC
FCP-2100
FCP-75
FCP-300
Type LC
30 dB for multi-mode with 9/125 micrometer cable
@ 1310 nm.
0.079 A
0.079 A
32° to 120°F (0° to 49°C), 0% to 93%
Non-condensing at 90°F (30°C)
FIK-FSL
Advertisement
Table of Contents
Related Manuals for Fike FIK-FML
Summary of Contents for Fike FIK-FML
- Page 1 1.1 FIK-FML (Fiber-Optic Multi-Mode, Receiver) The FIK-FML is a fiber module that is used as one channel to transmit or receive communications with the FIK-NVCM (Network Voice Control Module) or FIK-NIC (Network Interface Card). It allows the multi-mode fiber to network between the FIK-FML module boards.
- Page 2 Location 4 in Figure 3 and Figure 4. FIBER MODULES:FIK-FSL AND FIK-FML NOTE 1: INSTALL A MAXIMUM OF TWO BOARDS PER INSTALLATION.THE FIBER MODULES CAN BE COMBINED. Figure 3 illustrates the FIK-FML/FIK-FSL installed to the Figure 4 illustrates the FIK-FML/FIK-FSL installed to the FIK-NIC. FIK-NVCM.
- Page 3 Note 1: Use standard ST connector fiber-optic cable, multi-mode, up to 200 µ (optimized for 62.5/125 µ). Note 2: Signal loss up to 8dB maximum between nodes. Table 3 FIK-FML Terminal Wiring Designations Table 4 lists the FIK-FML switch settings and drive currents. SW1-1 SW1-2...
- Page 4 4.4 FIK-FSL Installation Wiring Terminals Table 5 lists the FIK-FML installation wiring terminals. Designation Description Plugs on to P5 (Port 1) or P6 (Port 2) of the FIK-NVCM or FIK-NIC. Top connection connects to the receiving fiber (IN). Bottom connection onnects to the transmitting fiber (OUT).
