FFS2001 Series
Command
Process Bar
Buttons
Control Boxes
The top of the GUI contains a menu bar, a command bar, a camera bar, a processes bar, a macro bar, and a toolbar
containing control buttons. The center region of the GUI contains a live image captured by the CCD. The bottom
of the GUI contains control boxes for manipulating the fiber handlers and the splice head, as well as a status bar.
The following sections detail the functions of the GUI.
Menu Bar
Rev. A, August 14, 2024
Figure 19 FFS3 Graphical User Interface
Figure 20 Menu Bar
Chapter 4: Software
Menu Bar
Camera Bar
Macro Bar
Captured by
the Camera
Status Bar
