FFS2001 Series
Maximum Tension a
Mandrel Size
Accuracy
a. The proof tester is calibrated using standard weights that are hung off a pulley, so the tension settings are programmed in grams.
This maximum tension corresponds to 9.1 kg.
1.4.4 FFS2001PM Specifications
Accepted Fiber Cladding Diameters
Fiber Type
Size (L x W x H)
Rotation Alignment
Rotation Resolution
Rotation Travel
Extinction Ratio
1.4.5 FS2001WS Specifications
Accepted Fiber Cladding Diameters
Fiber Type
Size (L x W x H)
Rotation Alignment
Rotation Resolution
Rotation Travel
Extinction Ratio
Page 4
Proof Testing
Fiber Specifications
General Specifications
17.00" x 14.00" x 4.74" (431.8 mm x 355.5 mm x 120.4 mm)
PM Rotation Specifications
Fully Automated by End-View Alignment Technology or External
Stepper Motor Controller (0.01° Resolution)
Fiber Specifications
General Specifications
17.00" x 14.00" x 5.30" (431.8 mm x 355.5 mm x 134.7 mm)
PM Rotation Specifications
Fully Automated by End-View Alignment Technology or External
Stepper Motor Controller (0.01° Resolution)
89 N (20 lbs)
Ø2" (Ø50.8 mm)
±2%
80 to 200 µm
SM, MM, or PM
Feedback
190°
-35 dB (Typical)
80 to 200 µm
SM, MM, or PM
Feedback
190°
-35 dB (Typical)
