FFS2001 Series
• True Core Imaging™ for Automatic Fiber Alignment and Accurate Splice Loss Determination
• Automatic 3-axis Fiber Positioning System (Item #s FFS2001 and FFS2001PT)
Automatic 4-axis positioning system for PM rotation (Item #s FFS2001PM and FFS2001WS)
•
Filament Fusion Splicing Station with Automatic Post-Fusion Fire Polishing for Strength Enhancement
•
• Recoat Station for Acrylate Buffer Restoration
• Built-in Proof Tester / Tension Tester (Item #s FFS2001PT and FFS2001WS)
Personal Computer with Windows GUI and Networkable Database
•
• Analog BNC Inputs for Test and Measurement Equipment
3.2.4 Standard Accessories
When unpacking the FFS2001 Series splicing system for the first time, check to make sure that you have the
following accessories:
External Power Supply Unit
•
• DC Power Supply Cord
• AC Power Cord
Firewire Camera Cable
•
• RS-232 Cable
• PC, Monitor, Keyboard, Mouse, and Software
External Vacuum Pump
•
Clear Polycarbonate Tension Test Shield (Item #s FFS2001PT and FFS2001WS Only)
•
• Recoat Mold Injector System
• Color Coating Agent (Item #s FFS2001PM and FFS2001WS only)
Large Tank Regulator with Gas Line
•
• Tool Kit Containing:
o Lens Tissue
o Flat Head Screwdriver
o Filament Extraction Tool
o Eye Dropper
o Two (2) 3/32" Hex Keys
o Two (2) 5/64" Hex Keys
o 0.028" Hex Key
o 0.035" Hex Key
o 0.050" Hex Key
o Soft Cleaning "Toothbrush"
o 0-300 Gram Tension Gauge
Installation Instructions
The FFS2001 Series workstations accept an AC input range of 85 to 265 VAC, 47-63 Hz. Internally, the power supply
senses the AC voltage being supplied and adjusts automatically.
Connect the power cord (wall cord), four-pin external DC power cable between the power supply and the
workstation, the Argon gas line, external vacuum line, and both the serial and camera PC interface cables to the
back panel.
Turn on the computer.
Start the FFS2001 Series software by selecting the FFS3 icon on the desktop.
Open argon valves at the regulator and set at 10 psi before starting the unit.
