Acer Swift Go 14 Lifecycle Extension Manual page 34

Pry slightly to access the double-sided mounting tape underneath the LCD panel. Then
3.
carefully pull to detach the double-sided mounting tape. Repeat the same procedure to remove
the double-sided mounting tape on another side of the LCD panel.
Remove the LCD panel. Then carefully flip the LCD panel to access its connector.
4.
Detach and unroute the eDP cable from the LCD panel as shown in the illustration below.
5.
NOTE: When unrouting the cable, carefully lift the portion of the eDP cable (marked with
red dashed lines
underneath.
1-32
WEEE Annex VII Component:
LCD Panel
Figure 1-43. Detaching the Double-sided Mounting Tapes
as shown in the below illustration) to detach it from the adhesive tape
Figure 1-44. Detaching and Unrouting the eDP Cable
Disassembly Procedures
