Acer Swift Go 14 Lifecycle Extension Manual page 23

Remove the screw securing the USB board to the upper case.
4.
Release the USB board from the I/O port slots. Then remove the USB board from the upper
5.
case.
Screw Name
M 2.0 x 4.0
Disassembly Procedures
Figure 1-25. Removing the Screw
WEEE Annex VII Component:
USB Board
Figure 1-26. Removing the USB Board
Table 1-7. USB Board Screw
Screw Type Torque
1.8~2.2kgf.cm
Quantity
1
1-21
