RTC Battery Removal
Prerequisite:
Partially detach the mylar. Then disconnect the RTC battery cable from the mainboard
1.
connector.
Pry to detach the adhesive tape underneath the RTC battery. Then lift the RTC battery to
2.
release it from the compartment tab. Remove the RTC battery.
WEEE Annex VII Component:
RTC Battery
1-26
SSD 1 Module Removal
Figure 1-33. Removing the RTC Battery
on page
1-13
Disassembly Procedures
