Acer Swift Go 14 Lifecycle Extension Manual page 30

Remove the two (2) screws securing the mainboard to the upper case.
3.
Release the mainboard from the I/O port slots. Then remove the mainboard from the upper
4.
case.
Screw Name
M 2.0 x 4.0
1-28
Figure 1-35. Removing the Screws
WEEE Annex VII Component:
Mainboard
Figure 1-36. Removing the Mainboard
Table 1-9. Mainboard Screws
Screw Type Torque
1.8~2.2kgf.cm
Quantity
2
Disassembly Procedures
