Summary of Contents for Maxxus Hyper Extension Advanced
- Page 1 BENCH PRESS Hyper Extension with safety bars PRO Advanced...
- Page 2 Table of content Table of content Safety Instructions Technical data overview Parts list 5 - 7 Assembling steps 8 - 10 Cleaning/Maintenance/Disposal Warranty Training information Warm-Up/Stretching Notes...
- Page 3 Important information and safety instructions General information Please ensure that all people using the device have read and understood the assembly and operating instructions. The assembly and operating instructions must be regarded as part of the product and kept in a safe place so that they can be referred to at any time if necessary.
- Page 4 Tehnical data overview...
- Page 5 Parts list...
- Page 6 Parts list...
- Page 7 Parts list Pre-assembled part assembly...
- Page 8 Assembling steps Step 1: Lock the pre-assembled part B into the pre-assembled part A using: • 2 pcs Outer hexagon screws M10x80 (No. 32) • 4 pcs Flat washers Φ10 (No. 33) • 2 pcs Locking nuts M10 (No. 34) Step 2: Lock the reinforcing plate (No.
- Page 9 Assembling steps Step 3: Pull out the M16 Elastic bolt (small head) (A-2, No. 12). Lock it well after adjusting the Gear adjust- ment assembly (A-1, No. 3) to a suitable hole position. Step 4: Pull out the T-bolt (A-4, No. 19). Insert it well after adjusting the Hook leg assembly (A-3) to a suitable hole position.
- Page 10 Assembling steps Step 6: Lock the pre-assembled part C into the pre-assembled part A using: • 2 pcs Outer hexagon screws M10x20 (No. 29) • 2 pcs Flat washers Φ10 (No. 33)
- Page 11 Cleaning/ Maintance/Disposal Cleaning Please use only a slightly damp cloth for cleaning. Attention! Never use gasoline, thinner, or other aggressive cleaning products, as these may cause damage. The device is only suitable for private home and indoor use. Keep the device clean and free from moisture. Damage caused by body sweat or other liquids is not covered by the warranty under any circumstances.
- Page 12 Warranty* The warranty is 24 months and applies to new goods at the first purchase, beginning with the invoice or delivery date. During the warranty period, any defects will be repaired free of charge. If you find a defect, you are obliged to report it immediately to the seller.
- Page 13 Training information Training Preparations Before you start training, not only must the training equipment be in perfect condition, but you should also en- sure that your body is ready for training. If you have not engaged in strength or endurance training for a long time, consult your family doctor before starting your training and carry out a fitness check-up.
- Page 14 Warm-Up/Stretching Thighs Support yourself with your right hand against a wall or your exercise equipment. Lift your left foot backward and hold it with your left hand. Ensure your knee points straight down. Pull your thigh back until you feel a slight stretch in the muscle. Hold this position for 15-20 seconds.
- Page 15 Notes...
- Page 16 L E A D I N G B E Y O N D F I T N E S S NORDRING 80, 64521 GROß-GERAU WWW.MAXXUS.COM...
