Operation and Maintenance Manual
MODEL 45 TONGUE AND GROOVE NAILER
Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you
are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or
contact the closest Powernail Dealer for help. Please retain this information for future reference.
REV 2024.04.25
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powernail 45
Summary of Contents for Powernail 45
- Page 1 Read this manual before you use this Nailer. Follow all safety warnings and instructions. If you are uncertain about the operation of the Nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference. REV 2024.04.25...
-
Page 2: Table Of Contents
MODEL 45 by POWERNAIL®, for a period of 12 months from the date of purchase. MODEL 45 shall be free of defects in materials and workmanship and will meet POWERNAIL’s specifi cations in eff ect at the time of product shipment. -
Page 3: Operation
Do not use any nails other than Powernail Powercleats® (16 gauge) nails, which are specifi cally designed for use in the Model 45 Powernailer. Powercleats® (16 gauge) nails are available in 1-1/2", 1-3/4" or 2" lengths to accommodate 3/4″ to 5/8″ and 33/32″ tongue... -
Page 4: Schematic
MODEL 45 EXPLODED VIEW... -
Page 5: Parts List
MODEL 45 PARTS LIST ITEM # PART NO. DESCRIPTION Assembly REQ’D or Kit 08-45-00-010 SPRING CLIP TU / OVH 08-45-00-020 FEEDER CHANNEL 08-45-00-050 ROLLER PIN ASSEMBLY 08-45-00-05R ROLLER 08-45-00-130 FOOT SCREW 08-45-00-13N LOCKNUT 08-45-00-140 GATE 08-45-00-150 FOOT 16 & 19 08-45-00-160 SCREW &... -
Page 6: Drive Blade Replacement
2. Holding Nailer in left hand with Nailer tilted Driving Blade Assembly into Nailer Body, making so rear of Nailer is down, depress #37 Plunger certain the #45 Plunger Spring is inserted into Head slightly so #5R Roller is released from hole in Plunger Head. -
Page 7: Notes And Records
NOTES AND RECORDS... -
Page 8: Web Site
P/N: 06-CAPAW P/N: 06-CAPAB (5 x 1,000 Cleats) P/N: L200165 POWERNAIL® Warranty Registration Register your warranty on the web and you will automatically be entered to win a FREE!!! PowerPalm™. Scan this code with your phone to be taken to our warranty registration form...
