POWERNAIL
CO.
®
Model 50F Pneumatic Powernailer™
OPERATION AND MAINTENANCE MANUAL
MANUAL DE OPERACION Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
WARNING
Read this manual before you use this Powernailer®. Follow all safety warnings and
instructions. If you are uncertain about the operation of the nailer, call us directly
at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.
Please retain this information for future reference.
REV 17.08.10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Powernail 50F
Summary of Contents for Powernail 50F
- Page 1 Read this manual before you use this Powernailer®. Follow all safety warnings and instructions. If you are uncertain about the operation of the nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference.
-
Page 2: Table Of Contents
The Model 50F is designed for use with 1-1/4” to 1-3/4”, 18 gauge L-Cleat Powernails ® . The Model 50F nails from 3/8” to 3/4” fl ooring through the use of a FLEX adjustable foot assembly that can be adjusted to fi t diff erent fl ooring profi les. -
Page 3: Safety Instructions
fl ooring and is not to be used for purposes not specifi ed in the operations manual. Do not use any nails other than Powernail® Powercleats which are 18 gauge L-cleat nails specifi cally designed for use in any 18 gauge Powernailer. Powercleat nails are available in lengths of 1-1/4”, 1-1/2”... -
Page 4: Operating The Tool
fi t diff erent fl ooring from fl ooring profi les. 3/8” to 3/4” To use the Model 50F, properly position the tool on the fl ooring plank (See picture below). Pull up 3/4” and hold the black safety trigger to activate the 19 mm orange fi... -
Page 5: Air Supply
Adjust the FLEX Foot to your wood... FOOT ADJUSTMENT / NAIL LOCATION Flip the lever (1A) on the FLEX Foot to one side so the FLEX Foot is free to slide on the channel. Using a sample of your fl ooring, slide the FLEX Foot back on the channel and set the nose of the nailer (1B) on top of the fl... - Page 6 OPERATION, continued... Figure 5. LOADING THE FASTENERS 1. Insert a full stick of 1-1/4”, 1-1/2” or 1-3/4” 18 gauge Powercleats through the slotted Magazine Rear Cover(49) into the Magazine (47) Pull back the spring loaded Nail Pusher (39) over the nails until it contacts the last nail and slowly release the Nail Pusher.
-
Page 7: Safety Labels
6. Disconnect the tool from air supply before clearing jams, serviceing, adjusting or during non-operation. 7. Don’t point tool at people or animals while operating. Use Genuine Powernail Model 50F 1-1/4” to 1-3/4” 18 Gauge L-Powercleats 18 GA L-Cleats Made in Taiwan... -
Page 8: Clearing A Jam
CLEARING A JAM Disassembly: (See Figure 7.) 1) NOTE: Do not remove the four M4 screws (80). 2) Loosen the 4 M4 screws (78) with a 3mm allen wrench. 3) Slide the gate plate down until it is free from the nose.. 6) Lift the gate plate (72) off... -
Page 9: Troubleshooting Chart
TROUBLE SHOOTING CHART Here are some common issues that may occur during use. If the nailer is not working as it should, stop using the tool immediately and resolve the issue before continuing. PROBLEM POSSIBLE CAUSE SOLUTION 1. O-ring (34) in trigger valve is damaged. 1. -
Page 10: Schematic / Parts List
MODEL 50F PARTS LIST ITEM DESCRIPTION Avail. PART # ITEM DESCRIPTION Avail. PART # UM.HD.BOLT 09-50F001 SPRING 09-50F035 FLAT WASHER 09-50F002 BUMP FIRE TRIGGER 09-50F036 EXHAUST COVER, METAL 09-50F003 PUSHER GUIDE 09-50F037 SEAL 09-50F004 SPRING 09-50F038 HEX.SOC.HD.BOLT+SW 09-50F005 PUSHER 09-50F039... - Page 11 MODEL 50F SCHEMATIC...
-
Page 12: Nail Depth Chart
Part #: L125185 1½” 5 Pack (5 x 1,000 Cleats) Part #: L150185 1¾” 5 Pack (5 x 1,000 Cleats) Part #: L175185 ©Powernail Company 2017 POWERNAIL COMPANY, INC. 1300 Rose Road, Lake Zurich, IL 60047 US Phone: 1-800-323-1653 or 847-847-3000 www.powernail.com...
