POWERNAIL
CO.
Pneumatic Powernailer®
Models 445 XLL, XLS, LL, LS
OPERATION AND MAINTENANCE MANUAL
MANUAL DE OPERACION Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
WARNING
Read this manual before you use this Powernailer®. Follow all safety warnings and
instructions. If you are uncertain about the operation of the nailer, call us directly
at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.
Please retain this information for future reference.
rev. 2019.04.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pneumatic Powernailer 445 XLS and is the answer not in the manual?

Questions and answers

Related Manuals for Powernail Pneumatic Powernailer 445 XLS

Summary of Contents for Powernail Pneumatic Powernailer 445 XLS

  • Page 1 Read this manual before you use this Powernailer®. Follow all safety warnings and instructions. If you are uncertain about the operation of the nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference.

  • Page 2: Table Of Contents

    10 years from date of purchase, (“warranty period”); shall be free of defects in materials and workmanship and will meet POWERNAIL’s specifi cations in eff ect at the time of Product shipment. POWERNAIL will repair or replace, at its option, any Powernailer® that does not conform to this warranty.

  • Page 3: Safety Instructions

    Nailer is intended for use installing wood fl ooring and is not to be used for purposes not specifi ed in the operations manual. Do not use any nails other than Powernail Powercleats Nails which are specifi cally designed for use in any Powernailer. Powercleats Nails are available in various lengths. Contact your Powernail Dealer for Powercleats Nails.

  • Page 4: Operating Instructions

    Be sure to state the quantity of the part(s) required. activate it. Never hit the Nailer with excessive force or Contact your Powernail Dealer for the necessary parts with the metal end of the mallet, this will damage the or visit our parts store www.store.powernail.com Nailer.

  • Page 5: Seal Replacement

    SEAL REPLACEMENT: There are 7 seals that may require replacement. We 2. Remove the four (4) cap screws holding the recommend that you have your POWERNAIL Dealer Adapter Foot, Foot and Nail Channel assembly to the replace the Seals. main Body (see illustration).

  • Page 6: Schematic (445 Nailers)

    OPERATING INSTRUCTIONS, continued 8. Remove the Rubber Bumper (#24). the groove. Do this as quickly as possible to reduce stretching of the Tefl on ® Seal Ring. DO NOT OVER 9. Pull the Driving Blade Assembly out of the Nailer STRETCH THE TEFLON ®...
  • Page 7 Cylinder and screw the Piston onto the rod. Be sure the Piston is facing the correct way, ears up, hex down. For Step-by-Step Videos and Instructions, 5. Assemble the Driving Blade, Dowel Pin and Visit our Web Site at: www.Powernail.com...
  • Page 8 MODELS 445 XLL, XLS, LL, LS PARTS LIST PART NO. DESCRIPTION QTY REQ TU SEAL AVAIL ITEM 09-44529701 BODY 09-4453150 CAP (LOW PROFILE) 09-50P3202 1/4-20 X 5/8” S.H.C.S. W/PATCH (COVER) 09-44529729 PLUNGER WIPER METAL CAP O-RING SEAL S, A-5 09-44529759 3/8”...
  • Page 9 MODELS 445 XLL, XLS, LL, LS PARTS LIST PART NO. DESCRIPTION QTY REQ AVAIL ITEM # 09-44529705 ADAPTER FOOT 09-44529819 .030 PLASTIC SHIM 09-44529757 1/4-20 x 1/2” F.H.C.S. w/Patch (PAD) 09-44529736 1/2” ADAPTER PAD (Accessory) 09-44529737 5/8” ADAPTER PAD (Standard) 09-44529738 3/4”...
  • Page 10 Schematic #'s: 4, 10, 11, 12, 17, 18, 21 Schematic #'s: 4, 7, 10, 11, 12, 14, 15, 17, 18, 21, 22, 24, 28, 29, 35 (x2), 37 (x4) For Step-by-Step Videos and Instructions, Visit our Web Site at: www.Powernail.com...
  • Page 11 PNEUMATIC SEAL PART NUMBERS AND LOCATIONS...
  • Page 13 POWERNAILER MODEL 445 TROUBLE SHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTION Check air supply for 80 psi minimum to 110 psi 1. Zero or Low air pressure maximum 2. Lack of lubrication Manually lubricate through male air inlet fi tting Driving blade 3.
  • Page 14 STAPLER SAFETY DECALS Warning! • Read and understand the tool labels and manuals before operating. • Operators and others in work area MUST wear EYE and EAR protection. • Use safety glasses with side shields. • NEVER point tool at yourself or others in the work area.
  • Page 15 16-GAUGE POWERCLEATS...

  • Page 16: Depth Chart

    Part number: 02-PALM001 Pneumatic PowerPalm™ FLEX Power Roller Conversion Kit (for Models 445, 445FS) When comfort and control make the diff erence, Powernail’s new Tri-Glide Power Roller Conversion Kit allows the 445LS or 445FS to convert into a Tri-Glide Power Roller.
