6 Preventive maintenance
6.2.2 Checking the measuring system
 Check the MiniCODER and target wheel regularly for damage.
 Regularly check whether there are any foreign bodies in the installation space of
the MiniCODER.
6.2.3 Checking the MiniCODER fastening
Regularly check that the screws are tight.
 Insert the distance gauge into the installation space between the MiniCODER and
the target wheel.
 If necessary, unscrew the two screws counterclockwise and apply threadlocker to
the threads of the two screws.
 Screw the two screws clockwise into the mounting fixture and tighten them to the
permissible tightening torque:
● Steel screw in aluminum: 1 Nm
● Steel screw in steel: 1.5 Nm
 Remove the distance gauge.
Maintenance ist completed.
6.3 Cleaning
6.3.1 Consumables
● Lint free cloth
● Non-corrosive cleaning agent
6.3.2 Cleaning the MiniCODER
NOTICE Penetration of foreign bodies or liquids!
● Do not use a pressure washer.
 Clean the MiniCODER regularly with a damp, lint-free cloth.
Cleaning ist completed.
