1 About these operating instructions
Cleaning
Clean the surfaces.
Screw and spring washer
Perform rotating movement in the direction of the arrow.
Step-by-step instructions
● Listings without specified sequence
→ page 57 Page reference to another part of these operating instructions
1.5.5 Terminology and abbreviations
Air gap
AWG
CNC
Document number, re-
vision, date of issue
EMC
ESD
Evaluation electronics
Implants
Measuring scale
MiniCODER
58
Conventions
Distance between the measuring surface of the
MiniCODER and the outer circle of the target wheel
Abbreviation for "American Wire Gauge": Wire specifica-
tions based on the wire manufacturing process
Abbreviation for "Computerized Numerical Control": elec-
tronic process for controlling machine tools
Document number, revision and document issue date are
indicated on the front page.
Sequence: Document number (revision) – date of issue
Abbreviation for "Electromagnetic Compatibility"
Abbreviation for "Electrostatic Discharge" (ESD)
General designation for a control system for machine tools
or a higher level control system
General designation for active medical implants (for exam-
ple, pacemakers), passive medical implants (for example,
heart valves) or medical devices worn on the body (for ex-
ample, insulin pumps).
General designation for target wheel, rack or slotted disk
These operating instructions are primarily concerned with
target wheel applications. The same applies to other mea-
suring scales.
Designation for the product family of the GEL 24xx product
groups.
This designation is also used as a general designation for
an encoder kit of the product group.
Lenord+Bauer
GEL 2449M
