3 Description
3.5.2 Type code
Signal pattern
M MHSSI (Mitsubishi High Speed Serial Interface) 2.5 Mbit
Reference mark
Z Tooth on tooth
Optional extras
H Resolution configurable up to 26 bits, independent of the maximum
speed.
P Resolution configurable up to 19 bits, depending on the maximum
speed.
Cable outlet MiniCODER
L Tangential, cable outlet left
1 m= 1.0
4 m= 0.4
2449 _ _ _ _ _ _ _ _ _ _
(1)
Other modules upon request
(2)
The delivery takes place with connected test connector from Lenord+Bauer.
76
Product identification
(1)
Module
Connection type
(2)
K Flying lead
Z 10-pin male connector (only available as cable length
100/120/200/250)
Cable length L
030 0.3 m
050 0.5 m
100 1.0 m
120 1.2 m
150 1.5 m
200 2.0 m
250 2.5 m
Cable design for temperature sensor (2 m)
– Without temperature sensor cable
