Setup
- continued
3) Connect external equipment.
• To protect the external equipment, turn off the main
power before making connections.
• Refer to your equipment user manual for further
information.
4) Connect the supplied power cord.
• The equipment should be installed close to an easily
accessible power outlet.
• Please attach power cord to the LCD monitor by
attaching the screw and clamp.
• Fully insert the prongs into the power outlet socket. A
loose connection may cause image degradation.
NOTE:
If you use this monitor at AC 220 - 240V,
please refer to "Safety Precautions and Maintenance &
Recommended Use" sections of this manual for proper
selection of AC power cord.
5) Switch on the power of all the attached

external equipment.

When connected with a computer, switch on the power
of the computer first.
6) Operate the attached external equipment.
Display the signal from the desired input source.
Screw Clamp
Screwhole for Clamp
7) Adjust the sound
Make volume adjustments as required.
8) Adjust the screen See page 26.
Make adjustments of the screen display position when
necessary.
9) Adjust the image See page 26.
Make adjustments such as brightness or contrast when
required.
10) Recommended Adjustments
To reduce the risk of the "image persistence", please
adjust the following items based on the application
being used:
"DATE & TIME" and "SCHEDULE SETTINGS"
See pages 27 and 28.
"SCREEN SAVER", and "SIDE BORDER COLOR"
See page 29.
It is recommended that the "FAN CONTROL"
setting be turned to ON also. See page 30.
English-16
