Setup Procedure

1. Determine the installation location
CAUTION: DO NOT ATTEMPT TO INSTALL THE LCD
MONITOR BY YOURSELF.
Installing your LCD display must be done by a qualified
technician. Contact your dealer for more information.
CAUTION: MOVING OR INSTALLING THE LCD MONITOR
MUST BE DONE BY TWO OR MORE PEOPLE.
It is recommended that 4 people move or install
the LCD Monitor, due to its weight of almost
66.0kg (145.5lbs).
Failure to follow this caution may result in injury if the LCD
monitor falls.
CAUTION: Do not mount or operate the display upside
down, face up, or face down.
CAUTION: This LCD has a temperature sensor and cooling
fan. If the LCD becomes too hot, the cooling fan
will turn on automatically. If the LCD becomes
overheated and the cooling fan is running, the
"Caution" menu will appear. If the "Caution"
menu appears, discontinue use and allow the
unit to cool. When the LCD monitor is used in
an enclosure or with protection on the LCD
surface, please check the inside temperature of
monitor in the "HEAT STATUS" menu
(See page 28). If the temperature is hotter than
normal, turn the "cooling fan" function to ON in
the SCREEN SAVER OSM (See page 24).
IMPORTANT: Lay the protective sheet, which was wrapped
around the LCD monitor when it was
packaged, beneath the LCD monitor so as
not to scratch the panel.

2. Install the remote control batteries

The remote control is powered by 1.5V AA batteries.
To install or replace batteries:
1. Press and slide to open the cover.
2. Align the batteries according to the (+) and (–)
indications inside the case.
3. Replace the cover.
CAUTION: Incorrect use of batteries can result in leaks
or bursting.
Be careful especially about the following points.
• Place "AA" size batteries matching the + and - signs on
each battery to the + and - signs of the battery
compartment.
• Don't mix battery types.
• Don't combine new batteries with used ones.
It causes shorter battery life or leakage of batteries.
• Remove dead batteries immediately to prevent battery
liquid from leaking into the battery compartment.
Don't touch exposed battery acid, it cause damage to
your skin.
NOTE: If you do not intend to use the Remote Control for a
long period, remove the batteries.
3. Connect external equipment
(See pages 12-17)
• To protect the connected equipment, turn off the main
power before making connections.
• Refer to your equipment user manual.
4. Connect the supplied power cord
• The power outlet socket should be installed as near to
the equipment as possible, and should be easily
accessible.
• Fully insert the prongs into the power outlet socket.
Loose connection may cause noise.
• Please attach power cord to the LCD monitor using the
screw and clamp (included).
NOTE: Please refer to "Important Information" section of
this manual for proper selection of AC power cord.
Screw
Clamp
Screw hole for clamp
5. Switch on the power of all attached

external equipment

When connected with a computer, switch on the power of
the computer first.
6. Operate the attached external
equipment
Displays the desired signal from the external equipment.
7. Adjust the sound
Makes adjustments when required.
8. Adjust the screen (See pages 20-28)
Makes required adjustments to the screen display position
or if there is distortion.
English-9
