CLoCK
Vga and rgB/HV input only
CLoCK PHaSE
Vga, rgB/HV, DVD/HD
input only
H rESoLution
DVi, Vga, rgB/HV
input only
V rESoLution
DVi, Vga, rgB/HV
input only
ZooM MoDE
all inputs except for tV
BaSE ZooM
16:9
HDMi, DVD/HD,
ViDEo input only
14:9
HDMi, DVD/HD,
ViDEo input only
DYnaMiC
HDMi, DVD/HD,
ViDEo input only
oFF
CuStoM
ZooM
16:9, 14:9, CuStoM only
H ZooM
16:9, 14:9, CuStoM only
V ZooM
16:9, 14:9, CuStoM only
H PoS
16:9, 14:9, CuStoM only
V PoS
16:9, 14:9, CuStoM only
inPut rESoLution
Vga and rgB/HV input only
aDJuSt rESEt
BaLanCE

auDio

trEBLE
BaSS
PiP auDio
auDio rESEt

SCHEDuLE

oFF tiMEr
SCHEDuLE SEtting
SCHEDuLE LiSt
Press + to expand the width of the image on the right of the screen.
Press - to narrow the width of the image on the left.
adjusts the visual "noise" on the image.
adjusts the horizontal size of the image.
adjusts the vertical size of the image.
Select the aspect ratio of the screen image.
Choose the zoom method
Same aspect ratio as the LCD panel.
14:9
Expands a 4:3 picture to fill the screen in a non-linear (non-proportionate) manner and
some of the image will be lost due to expansion. DYnaMiC is the same as FuLL size im-
age when HDtV 1080i signal is input.
Selecting "oFF" will display the image in a 1 by 1 pixel format. (if the input resolution is
higher than a 1920 x 1080 resolution, the image will be scaled down to fit the screen.
Displays an image as large as possible without changing the aspect ratio or cutting off
part of the image.
Maintains the aspect ratio while zooming.
amount of horizontal zoom. Can be adjusted for each BaSE ZooM setting.
amount of vertical zoom. Can be adjusted for each BaSE ZooM setting.
Horizontal position. Can be adjusted for each BaSE ZooM setting.
Vertical position. Can be adjusted for each BaSE ZooM setting.
if there is a problem with signal detection, this function forces the monitor to display the
signal at the desired resolution.
if no problem is detected, the only available option will be "auto".
resets the following settings within the aDJuSt menu back to factory setting:
auto aDJuSt, H PoSition, V PoSition, CLoCK, CLoCK PHaSE, H rESoLution, V rESoLu-
tion, ZooM MoDE, inPut rESoLution.
Selects source of PiP audio.
resets "auDio" options back to factory settings.
Sets the monitor to power off after a length of time between 1 and 24 hours.
Creates a working schedule for the monitor to use. See page 34 for instructions.
List of schedules.
English-27
OSD Controls
- continued
