Setup Procedure

1. Determine the installation location
CAUTION: DO NOT ATTEMPT TO INSTALL THE LCD
MONITOR BY YOURSELF.
Installing your LCD display must be done by a qualified
technician. Contact your dealer for more information.
CAUTION: MOVING OR INSTALLING THE LCD MONITOR
MUST BE DONE BY TWO OR MORE PEOPLE.
Failure to follow this caution may result in injury if the LCD
monitor falls.
CAUTION: Do not mount or operate the display upside
down, face up, or face down.
CAUTION: This LCD has a temperature sensor and cooling
fan. If the LCD becomes too hot, the cooling fan
will turn on automatically. If the LCD becomes
overheated and the cooling fan is running, the
"Caution" menu will appear. If the "Caution"
menu appears, discontinue use and allow the
unit to cool. When the LCD monitor is used in an
enclosure or with protection on LCD surface,
please check the inside temperature of monitor
by "HEAT STATUS" (See page 28). The
temperature is too hot than normal condition,
please set "cooling fan" to ON on SCREEN
SAVER function (See page 24).
IMPORTANT: Lay the protective sheet, which was wrapped
around the LCD monitor when it was
packaged, beneath the LCD monitor so as
not to scratch the panel.

2. Install the remote control batteries

The remote control is powered by 1.5V AA batteries.
To install or replace batteries:
1. Press and slide to open the cover.
2. Align the batteries according to the (+) and (–)
indications inside the case.
3. Replace the cover.
CAUTION: Incorrect use of batteries can result in leaks
or bursting.
Be careful especially about the following points.
• Place "AA" size batteries matching the + and - signs on
each battery to the + and - signs of the battery
compartment.
• Don't mix battery types.
• Don't combine new batteries with used ones.
It causes shorter battery life or leakage of batteries.
• Remove dead batteries immediately to prevent battery
liquid from leaking into the battery compartment.
Don't touch exposed battery acid, it cause damage to
your skin.
NOTE: If you do not intend to use the Remote Control for a
long period, remove the batteries.
3. Connect external equipment
(See pages 12-17)
• To protect the connected equipment, turn off the main
power before making connections.
• Refer to your equipment user manual.
4. Connect the supplied power cord
• The power outlet socket should be installed as near to
the equipment as possible, and should be easily
accessible.
• Fully insert the prongs into the power outlet socket.
Loose connection may cause noise.
• Please fix the power cord by attaching the screw and
clamper.
NOTE: Please refer to "Safety Precautions, Maintenance &
Recommended Use" section of this manual for
proper selection of AC power cord.
Screw
Clamper
Screw hole for clamper
5. Switch on the power of all attached

external equipment

When connected with a computer, switch on the power of
the computer first.
6. Operate the attached external equipment
Display the signal on the external equipment you wish.
7. Adjust the sound
Make adjustments when adjustment of the volume is
required.
8. Adjust the screen (See pages 20-28)
Make adjustments when adjustment of the screen display
position or distortion is required.
9. Adjust the image (See pages 20-28)
Make adjustments when picture adjustment such as the
brightness or contrast is required.
English-9
