Challenger Lifts CL10AV3 Service Bulletin

CL10AV3 LAUNCH
10K VERSYMMETRIC® ADJUSTABLE WIDTH 2-POST LIFT
Overview:
We are pleased to announce a significant upgrade for the
CL10V3 – our Adjustable Width Feature. This enhancement
is part of our commitment to providing flexible and innovative
solutions to meet the ever-evolving needs of automotive shops.
SERVICE BAY SPECIFICATIONS
HEIGHT: 12' minimum
14' recommended
WIDTH:
DEPTH: 24' recommended
POWER: 208-230v, 1pH, 30 Amps
PRODUCT SPECIFICATIONS
MODEL NUMBER CL10AV3
Description Standard
Lifting Capacity
Lift Configuration Versymmetric
Rise Height
Height of Columns 11' 2" or 11' 8"
Max. Extended
Cylinder Height
Adjustable Width
11' 61/2"
Overall
Drive Thru Clearance (-12") 100"
Floor to Overhead
10' 81/2" or 11' 21/2"
Switch
Front Arm Reach
Rear Arm Reach
Screw Pad Height
Inside Columns (-12") 110"
Low Lock Height
Rise Time Standard: 38s QuickCycle™: 24s (est.)
Max. Load per Arm
ALI Certified
®
challengerlifts.com | 800-648-5438
CL10AV3-2 CL10AV3-3
2' Extensions 3' Extensions
10,000 lbs.
, 3-Stage Front & Rear
®
741/8"
13' 2" or 13' 8" 14' 2" or 14' 8"
11' 11"
12' 1/2" 12' 61/2"
(-6") 106" (MAX) 112"
12' 81/2" or 13' 21/2" 13' 81/2" or 14' 21/2"
Min. 20" Max. 42"
Min. 375/8" Max. 60"
Min. 37/8" Max. 61/8"
(-6") 116" (MAX) 122"
12" Net Rise
2,500 lb.
☑
MODEL # CL10AV3
WIDTH CONFIGURATIONS
To better serve our customers' diverse lifting needs and the
growing demand for Electric Vehicle service, we've upgraded
our CL10V3. This new adjustable design ensures that our
entire CL Series can now accommodate a wider range of
vehicles, while providing your technicians with more space to
work efficiently. Add flexibility to your shop with the enhanced
width and height adjustability.
Narrow: Space Constraints or Express Pads configuration
Universal: Cars, SUVs, Trucks, Most Electric Vehicles
Wide: Optimal for Cars, EVs and Luxury vehicles
*The CL10A can also be set at the current 11' 10" width.
NARROW
SERVICE BULLETIN
7-15-2024
UNIVERSAL WIDE
SB.07-01-24 : CL10AV3
