Danfoss VLT FC 102 Installation Manual page 83

VLT® Frequency Converters, 90–400 kW
D4h
L1, L2, L3
+DC, –DC / +Regen, –Regen
Danfoss A/S © 2024.06
L1, L2, L3
D4h
U, V, W
+R, –R
+R
–R
U, V, W
+Regen
–Regen
+DC
–DC
M10 [19 Nm (168 in-lb)]
M10 [19 Nm (168 in-lb)]
M10 [19 Nm (168 in-lb)]
M10 [19 Nm (168 in-lb)]
M10 [19 Nm (168 in-lb)]
M8 [9.6 Nm (84 in-lb)]
17 13
mm mm
AN41701949085202-000201 / 130R1276 | 83
