1 General Information

• The SADPmini is a battery powered portable instrument. It is a fully self-contained
unit incorporating the moisture sensor, signal conditioning circuitry, memory
management, graphics display, membrane keyboard, Real Time Clock, onboard
battery and charger circuit.
• The SADPmini operation is controlled by a user-friendly software interface
incorporating multiple menus, hot key combinations, information displays and control
functions.

2 Features

Basic SADPmini
• 128 x 64 dot backlight LCD graphical display.
• Tactile membrane keypad, coupled with an easy to operate user interface.
• Operates from an internal rechargeable Lithium Ion battery.
• Battery life in excess of 250 hours* continuous use, from fully charged.
• Full charge time approximately 6 hours. Only use the Charger supplied with
SADPmini
• 7 selectable moisture units (ºC, ºF, ppm(V), ppm(W), ppb, g/m3 and lb/MMSCF).
• Pressure compensated moisture readings in 4 selectable units of pressure (psig, barg,
kg/cm2g and Kpag).
• Battery life Indicator.
• Built in Automatic Calibration (AutoCal).
• Built in Single Point Calibration (SPC).
• On board Real Time Clock.
• User settable security access.
• Sample gas flow temperature indication.
4-20mA Option (all the Basic SADPmini features plus)
• 4-20mA Loop Powered output.
Full Logging Option (all the 4-20mA option features plus)
• Stores up to 16000 data points.
• 20 definable alphanumeric TAG references, including 1 preset.
• Up to 20 blocks of data stored under each TAG reference.
• Review stored data in tabular and graphical form.
• RS485 Serial Communication to dedicated PC software.
• Download stored data in CSV format.
• Real Time logging to connected PCs.
• Thermal printer driver facility.
