24 Appendix D – SADPmini Specification
Unit Details
Dewpoint Ranges:
Accuracy:
Resolution:
Output
4-20mA loop powered:
Display
Type:
Keyboard:
Type:
Sensor
Operating Principle:
Temperature
Operating Temperature:
Storage Temperature:
Serial Communications (logging version)
Type:
Data Format:
Baud Rate:
No of Addresses:
Power Supply
Supply Voltage:
Output:
Battery
Cell:
Charging:
Capacity
Enviromental
Approvals:
EMC:
Physical
Weight:
Dimension (W,H,D)
'*'
Battery capacity is quoted at room temperature. The battery capacity will degrade as the
ambient working temperature falls.
–80ºC DP to -20ºC DP
–80ºC DP to 0ºC DP
–80ºC DP to +20ºC DP
–110ºC DP to -20ºC DP
–100ºC DP to 0ºC DP
± 2ºC DP over full range
12-bits
< ± 0.25% full range error
Blue 128 x 64 Dot LCD Graphics display with LED backlight.
5-key metal dome tactile membrane keyboard
Ultra High Capacitance AL
-10ºC to +50ºC
-20ºC to +60ºC
RS485
1 Start bit, 1 Stop bit, No Parity and No hardware handshaking
9600
32
100-240VAC, 50-60Hz, 400mA
6VDC, 15W
3.6V Li-Ion 2.3Ah capacity
Full Charge in 6 hours.
Only use the Charger supplied with SADPmini
Minimum of 250hrs* on full charged battery
CE
Certified to BS EN 61326-1
1.1kg (2.4lbs)
97 x 112 x 202mm ( 3.82" x 4.41" x 7.95")
