11.1.7 Time and Date

Description – This function allows the user to view the set 'Time' and 'Date' without
having to enter the Set Clock function (see section 11.1.8).
Operation – In the 'Setup Menu' select the 'Time and Date' option.

11.1.8 Set Clock

Description – The Clock option allows the user to set the SADPmini internal Real
Time Clock.
Operation – In the 'Setup Menu' select the 'Set Clock' option. The user is prompted
to enter the Date in the DD/MM/YY format followed by the time in the HH:MM:SS
in 24-hour format.
Note: Although the seconds digits are displayed they are not selectable

11.1.9 Information

Description – The Information menu displays all of the SADPmini current settings.
Operation – In the 'Setup Menu' select the 'Information' option. The 'Information'
sub-menu allows the user to run through the displayed data using the '' and ''
keys. The menu can be exited by pressing the '' key at any location or by scrolling
to the Exit option.
Note: There are no selectable operations from this menu; it is purely for information purposes.
Displayed Information
VerNo
Serial
Read L
Read H
ACAL
SPC Pt
SPC Va
Units
P Unit
Press
Sensor
4mA
20mA
Epot
Exit
Description
5.11 Software Version Number
500101 Unit Serial Number
-80.0 Lower Limit
20.0 Higher Limit
10.0 AutoCal Value
20.0 Single Point Calibration Action Point.
20.0 Single Point Calibration Offset Value.
ºC Currently Set Engineering Units
barg Currently Set Pressure Units
00.0 Currently Set Pressure Value in Current Units
B Type of Sensor fitted to SADPmini
-80.0 Low mA output in Currently Set Engineering Units.
20.0 High mA output in Currently Set Engineering Units.
384 Position of the electronic AutoCal potentiometer
Exit option
