9 The Normal Display screen

When the SADPmini is ON, it displays the moisture level of the gas that the sensor is
exposed too. When the head is lowered, the sensor is no longer exposed to the gas and is
dried down by the desiccant in the head.
Moisture Reading
Moisture Units
Pressure Value and units
The Display always shows the current moisture level that the internal sensor is
exposed too. The current engineering units are clearly indicated on the display as well
as any pressure compensation performed.

10 SADPmini operating principles

Two distinct and separate menus control the SADPmini. Each of these menus is
described in a separate section below:

10.1 Navigating through Menus

The SADPmini is predominantly menu driven. To navigate around the menus use the
'' and '' keys to move the cursor bar (negative image) through the options
available within the menu and use the '' key to select the option required. The ''
key has no function within menu screens.

10.2 Entering Numerical Data

The basic principle used to enter numerical values is described here.
The display will indicate a number in a format appropriate to the required input, the
first character of which will be displayed as a negative image to indicate it is active.
Use the '' and '' keys to select the required number between 0 and 9 then press the
'' key to select and proceed to the next character. Continue this process until all
characters are entered. Pressing the '' key, at any point, enters the numerical value
currently displayed.
-27.4
ºC Dewpoint
@ 1.0barg
Examples of the Main Display Screen
Page 9 of 33
9144
ppm[V]
