Pressing the '' key starts the logging process and brings up the 'Internal LOG'
display screen, which indicates the current moisture value, the number of data points
read and the TAG reference where the data is stored. Pressing the '' key at any
point will stop logging.
Note: A minimum of 4 stored data readings is required for the data to be reviewed by the
SADPmini.

11.2.2 Review Data

Description – This function allows the user to review data stored in the unit's internal
memory in both tabular and graphical format.
Operation – In the 'Logging Menu' select the 'Review DATA' option. The user is
then presented with the 'Review TAGs' menu showing all current TAG references.
Highlight the required TAG reference and press the '' key to move to the block
selection screen.
The selection screen shows the TAG reference, block number plus the date & time
when data was stored. The SADPmini by default displays the most current data block
first and subsequently runs through the remaining blocks in chronological order.
Pressing the '' key displays the next block of information.
Pressing the '' key displays the select block and the associated data in graphical
format.
Note: 'EMPTY' means the TAG reference has not been defined using 'Create TAG'.
The graphical displayed shows the stored data vs number of readings
Default TAG

0
-35.7
Page 18 of 33
TAG Reference
Block Number.
1
Cursor.
Moisture curve
Moisture value @ cursor
position.
Number of Data Points
20
