A.1 Rear Panel USER IO Connector
The 'USER IO' connector is for future use and no functionality is implemented at this
time.
Pin
1
2
3
4
5
6
7
8
34
Rear Panel Connector Pinout Details
5
10
15
Description
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Fig. A.1 USER I/O Connector Pin Identification
1
6
11
Pin Description
9 N/A
10 N/A
11 N/A
12 N/A
13 N/A
14 N/A
15 N/A
