Summary of Contents for Samcon ExCam XPT Q6075

  • Page 1 XPT Q6075 ExCam User Manual User Manual...
  • Page 2: Table Of Contents

    Table of contents Introduction ......................4 Technical data ......................4 Explosion protection .................... 4 Electrical parameters of the camera ..............5 Connection cable Ex-d - Ex-e (ASKDP03-T) ............5 Video-technical characteristics ................6 Other technical data .................... 6 Safety Instructions ....................7 Assembly ........................
  • Page 3 Table of Figures and Charts Fig. 2-1 Sectional view of ASKDP03-T ................6 Fig. 5-1 ExCam XPT Q6075 equipotential bonding ............11 Fig. 5-2 Camera (Ex-d) and terminal box (Ex-e) .............. 12 Fig. 5-3 Video Tutorial ExTB-3 ..................13 Tab. 5-4. Wire assignment of terminal box ExTB-3 ............13 Fig.
  • Page 4: Introduction

    Introduction In the ExCam XPT Q6075 is a powerful IP dome camera of the latest generation, with 2- megapixel resolution at 1920x1080p points. It is certified by ATEX, IECEx & EAC-Ex (and more). This dome camera can endlessly rotate around its own axis. When tilted, it covers a 180°...
  • Page 5: Electrical Parameters Of The Camera

    TÜV 18 ATEX 8218X IECEx Certificate of Conformity: IECEx TUR 18.0023X EAC-Ex TUR Report: RU C-DE.AБ.61.B.00381/19 IA No: MASC MS/18-3256X Further certification: https://www.samcon.eu/en/products/network/excam-xpt-q6075 Electrical parameters of the camera 24VDC Power input: Permissible temperature range: -50°C < T < +60°C Power supply: 24 VDC Power consumption: approx.
  • Page 6: Video-Technical Characteristics

    Fig. 2-1 Sectional view of ASKDP03-T Video-technical characteristics We use the AXIS Q6075 Dome Camera in a pressure-resistant enclosure. For details, ® please refer to the Product Documentation, video-technical data of AXIS https://www.axis.com/products/axis-q6075 Other technical data Camera (Ex-d) Terminal box (Ex-e) 0°C …...
  • Page 7: Safety Instructions

    The camera is to be operated in sound conditions and in the intended way. Attention! Only original parts of SAMCON Prozessleittechnik GmbH may be used for repairs. Repairs concerning the explosion protection may only be carried out in accordance with the nationally applied regulations and by SAMCON Prozessleittechnik GmbH.
  • Page 8: Assembly

    Assembly Work preparation: Attention! Prepare your work carefully and in accordance with the relevant regulations. Attention! Depending on classification of hazard areas, a work approval has to be obtained. When you open the pressure-resistant enclosure under volt- age, it is absolutely necessary to prevent potentially explosive atmos- phere! To ensure the best image quality delivered by the network camera, plan the installation site carefully (consider light conditions, object distance or size, angle and minimum object...
  • Page 9 Drawings for drill hole patterns and further information can be viewed on our product page: Quick link: https://www.samcon.eu/en/products/network/excam-xpt-q6075/ Option mounting accessories WALL MOUNT EXCAM XPT (01538-001) Wall bracket Wall bracket for the T08-TNXCD series WMB-... Suitable for hanging the camera on walls.
  • Page 10: Electrical Connection

    Electrical connection Attention! The electrical connection of the equipment must only be carried out by officially qualified and skilled personnel! Attention! ® It is absolutely necessary to ground the ExCam series housing via the PA connection. Attention! The minimum length of the connecting cable must not be less than three meters! The connection cable must be protected! Attention! Please pay attention to the national security, installation and accident...
  • Page 11: Equipotential Bonding/Grounding

    Equipotential bonding/Grounding Fig. 5-1 ExCam XPT Q6075 equipotential bonding Equipotential bonding/grounding of the camera body is absolutely necessary, in order to avoid static charges and formation of sparks. For this purpose, a screw terminal is provided at the rear side, at the bottom (right) (see Figure 5.1). The cross-section of the equipotential...
  • Page 12: Connection Work On The Device (Terminal Box)

    Connection work on the device (terminal box) ExTB-3 Fig. 5-2 Camera (Ex-d) and terminal box (Ex-e) Attention! Connect the device the electric mains exclusively via the box ExTB-3 terminal! Attention! Never open the Ex-e terminal box under voltage! Attention! Adhere to the international installation regulations for connection chambers with increased safety (Ex-e).
  • Page 13 Video Tutorial: Observe our video tutorial: “SAMCON 01 Installation and Wiring Connection to ExTB-3” https://go.samcon.eu/v01 Fig. 5-3 Video Tutorial ExTB-3 The pin assignment of the ASKDP03-T is executed in accordance with the standard EIA/TIA-568B for 100BaseTX and 24VDC, as follows:...
  • Page 14 ExCam XPT Q6075 Fig. 5-5 Sample circuit of terminal box ExTB-3 Fig. 5-6 Photo of the occupied terminal box ExTB-3 Doc.-ID: 200514-PT08BA-SS-ExCam XPT-Q6075_en_rev.00.docx, Page 14 of 28...
  • Page 15: External Connection And Protection

    Bring the twisted pair composite approximately 10mm close to the ter- minals, in order to ensure the immunity to disturbance. Attention! Use only terminals approved by SAMCON. Attention! Finally, check your network installation by per Class-D Link Test. External connection and protection There are several options of assigning the ExTB-3 terminal box in a safe area: 5.3.1...
  • Page 16: Routing Via Exconnection Rail (Optional Accessories)

    Attention! Cables and wires must comply with the requirements of the IEC 60079-0/1/7 & 14. Attention! The supply line must have a sufficient cross-section. The cable pro- tection must comply with national and international regulations. 5.3.2 Routing via ExConnection Rail (optional accessories) Fig.
  • Page 17: Appropriate Cables & Cable Entries

    To see non-binding configuration and planning guidelines, please visit: https://www.samcon.eu/fileadmin/documents/en/99-Knowledgecenter/Cable-Gland-selection-for-Ex-d-enclosures.pdf In particular for installations which require a suitable barrier gland, make sure that you handle them correctly and adhere to the rules and notes given in the respective mounting instructions.
  • Page 18 Video Tutorial: Observe our video tutorial: “SAMCON 02 Installation Ex d gland” https://go.samcon.eu/v02 Fig. 5-9 Barrier gland Doc.-ID: 200514-PT08BA-SS-ExCam XPT-Q6075_en_rev.00.docx, Page 18 of 28...
  • Page 19: Cable Kits - "Plug And Play" Connection Packages

    5.3.4 Cable kits - "plug and play" connection packages As an option, there are various cable kits for different cables are available in different lengths. The connection packages include everything you need for a professional system installation:  10/25/95 m SKDP03-T system cable, digital (a) ...
  • Page 20 Connection packages available: Length Non-armoured cable Armoured cable SKDP03-T ASKDP03-T SKDP03-T CABLE EXCAM 10M ASKDP03-T CABLE EXCAM 10M 10 meters (01540-001) (01543-001) This cable set includes: This cable set includes: 10 meters SKDP03-T system cable, digital 10 meters ASKDP03-T system cable, digital 1 x barrier gland Ex-d 1 x bolted connection Ex-d 5 ml Loctite 243 screw locking...
  • Page 21: Fusing

    Tab. 5-12 Recommendation for fusing 5.3.6 Plug assignment (RJ45) The data transfer of the ExCam XPT Q6075 series uses a 100 Mbit/s Ethernet connection (100BASE-TX). If the cable termination uses a plug, (figure 5.3) it has to be plugged into the associated slot of the network device.
  • Page 22: Tests Prior To Switching On Voltage

    Attention! Finally, check your network installation by per Class-D Link Test. Observe our video tutorial: “SAMCON 03 Mounting and installing the RJ45 jack to SAMCON cables” https://go.samcon.eu/v03 Fig. 5-13 Plug assignment RJ45 5.3.7 Tests prior to switching on voltage Attention! Prior to commissioning, all tests as indicated by the national regula- tions have to be executed.
  • Page 23: Opening The Pressure-Resistant Housing

    To open the TNXCD housing, you need a special tool. The customer should not open it. If you think that the housing has to be opened for unforeseeable reasons, please contact our support tem at first (Support@samcon.eu). Always adhere to the explosion-relevant rules: „WARNING –...
  • Page 24: Network Access And Visualization

    Interface, please see the User Manual for Axis or visit the following website: https://www.axis.com/products/axis-q6075 At delivery, the ExCam XPT Q6075 is set to the applicable net frequency (50Hz or 60Hz). If the camera is used at a location with a differing net frequency, a flickering of the picture might be noticeable, particularly in surroundings with fluorescent tubes.
  • Page 25: Password/ Identification

    It can also be used to manually assign a static IP address. For this pur- pose, the ExCam XPT Q6075 network camera has to be installed in the same physical network segment (physical subnet) as the computer on which the AXIS IP Utility is running.
  • Page 26: Maintenance/ Modification

    Reparation Reparations must only be carried out with original parts of SAMCON Prozessleittechnik GmbH. Damaged pressure-resistant housings have to be replaced completely. In case of doubt, send the part in question back to SAMCON Prozessleittechnik GmbH.
  • Page 27: Drawings & 3D Models

    Drawings & 3D models All drawings, 3D models, certificates and other information are available in the download area of the product page on our website: https://www.samcon.eu/en/products/network/excam-xpt-q6075/ If you wish additional technical information, please contact us at: support@samcon.eu Doc.-ID: 200514-PT08BA-SS-ExCam XPT-Q6075_en_rev.00.docx, Page 27 of 28...
  • Page 28 Schillerstraße 17, 35102 Lohra-Altenvers www.samcon.eu, info@samcon.eu fon: +49 6426 9231-0, fax: - 31...
