Camera Settings - Rexing M2 MAX PRO Quick Start Manual

Camera Settings

•
Video Resolution: 4K Front + 1080P Rear
•
Loop Recording: 1, 2 and 3 minutes. Video record is saved in segments.
When the storage card is full, the earliest recorded video will be
overwritten in order to maintain loop recording status. The time length in
menu is the duration of each recording.
•
Frequency: 50HZ, 60HZ
•
G-sensor Sensitivity: High, Medium, Low, Off
Note
The gravity sensor can pick up on when the car shakes violently or receives
an impact and the system will automatically save the current recording as a
protected file. This feature performs the same function as the manually
activated emergency lock. If the emergency mode is not activated
automatically, touch the
lock to protect the current video file.
Driver setting
Record resolution
Loop record
Light source frequency
Gsensor sensitivity
Parking monitor
icon during recording and apply the manual
3840*2160 (4K)
1 Minute
60 Hz
Low
Off
17
