Rosco Dual-Vision XC4 Installation Manual

For 2014 hino 195h
Hide thumbs Also See for Dual-Vision XC4:

Advertisement

Quick Links

Download this manual
2014 Hino 195H Installation Guide
This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2014 Hino 195H. Please
review the Installation Guidelines for grounding and making connections prior to installing. In this guide
you will find dash removal, wire locations, & mounting locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
th,
UPDATED October 15
2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Gray – Caution
Purple – New Installation
Red – Warning
Version 4.10.2
Proprietary and Confidential
2014 Hino

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual-Vision XC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rosco Dual-Vision XC4

Summary of Contents for Rosco Dual-Vision XC4

  • Page 1 2014 Hino 195H Installation Guide This guide will show the proper way to install a Dual-Vision XC4 Camera in a 2014 Hino 195H. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, & mounting locations.
  • Page 2 2014 Hino 195H Installation Guide Before starting your install, its best to prep the windshield for recorder mounting Giving the VHB tape time to cure before mounting the Recorder will give you a permanent bond and prevent recorders from falling. A- Squeeze to release primer and apply to the windshield B- Apply Primer to the bracket C- Wait for the primer to dry leaving a dull haze on the windshield...
  • Page 3 2014 Hino 195H Installation Guide Installation Layout Before starting your installation please take note of component mounting locations Version 4.10.2 Proprietary and Confidential 2014 Hino...

  • Page 4: Step 1 - Dash Removal

    2014 Hino 195H Installation Guide Step 1 - Dash Removal: • Carefully push in the sides of the glovebox and pull down to release (Photo A) • Locate the 5 Pin Tan connector located behind the glovebox (Photo B) • The wires on this Connector are labeled 12V &...

  • Page 5: Step 2 - Power Connections

    2014 Hino 195H Installation Guide Step 2 - Power Connections: • Connect the RED CONSTANT wire to the vehicles RED wire labeled 12 + 24V • Connect the YELLOW IGNITION wire to the vehicles YELLOW wire Labeled ignition Version 4.10.2 Proprietary and Confidential 2014 Hino...

  • Page 6: Step 3 - Antenna Mounting

    2014 Hino 195H Installation Guide Step 3 - Antenna Mounting: The Manufacture recommends mounting the antenna on the windshield Mount the antenna on the same side of the vehicle as the PDC Notice the angled part of the antenna is on the inside of the vehicle (Photo A & B).
  • Page 7 2014 Hino 195H Installation Guide Step 4 - PDC & Modem Connections: • Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A) • Connect the Antenna cable to the modem (Photo B) •...
  • Page 8 2014 Hino 195H Installation Guide Step 5 - PDC & Modem Mounting Location: • The PDC & Modem are located behind the glove box, with access from the lower dash • Secure the PDC with a zip tie to the factory bracket and secure the Modem to the factory harness IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM FALLING.
  • Page 9 2014 Hino 195H Installation Guide Step 6 - Camera Mounting and wire Routing: Large truck with split window Factory Sensor under Mirror Small Passenger Vehicle Recorder Mounting Mount away from sun visors & Inside the wiper swipe Emergency Vehicle For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A). If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a distraction to the driver (Photo B).
  • Page 10 2014 Hino 195H Installation Guide To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account and view activity to confirm proper angle Version 4.10.2 Proprietary and Confidential 2014 Hino...
