Made in America
Lifetime Guarantee
Thank you for purchasing this instrument from Intellitronix. We value our customers!
INSTALLATION GUIDE
1960-1963 Chevrolet Truck Analog
Direct Replacement Dash
Part #: AP6001
KIT COMPONENTS
One (1) Temperature Sending Unit (S8013) 1/8" NPT, 0-255 Deg., 1/2" NPT Bushing
One (1) Pressure Sending Unit (S8434) 1/8" NPT 0-100 PSI Oil Pressure
One (1) Universal GM Speedometer Sensor 7/8" NPT Industry Standard.
One (1) Mounting Kit
Seven (7) #6 x 1 1/4" Pan
Head Machine screws
WIRING INSTRUCTIONS
AP6001
Intellitronix
www.intellitronix.com
1 |
rev.10/13/2021)
Advertisement
Related Manuals for Intellitronix AP6001
Summary of Contents for Intellitronix AP6001
- Page 1 Made in America Lifetime Guarantee Thank you for purchasing this instrument from Intellitronix. We value our customers! INSTALLATION GUIDE 1960-1963 Chevrolet Truck Analog Direct Replacement Dash Part #: AP6001 KIT COMPONENTS One (1) Temperature Sending Unit (S8013) 1/8” NPT, 0-255 Deg., 1/2” NPT Bushing One (1) Pressure Sending Unit (S8434) 1/8”...
- Page 2 Resistors if the Tachometer does not have a push button for programing, please call Tech Support at Intellitronix, as you may need to send the gauge back to us to be reconfigured. There is no charge for this additional service.
- Page 3 If you don’t have an accurate reading. Run a new ground wire to engine without this the Gauge will not work properly. Note: Verify Ohm range of sender and match settings before cutting a wire or setting Dip switches for testing AP6001 Intellitronix www.intellitronix.com...
- Page 4 ECU, the resistor in the adapter kit will help pull a stronger signal for the tachometer. If your engine is a 4 cylinder, please call Tech Support at Intellitronix, as you may need to send the gauge back to us to be reconfigured. There is no charge for this additional service.
-
Page 5: Trip Distance
Ground at the Engine block. To find High and Low output wire color or pin location will need to be looked up by Vehicle vin or Model and year or (Consults Pinout Chart 3.)Speedometer - White (Intellitronix Speed Sender) - Disconnect the mechanical speedometer cable from the transmission and thread the new electronic sensor onto the transmission. This panel comes with a 3-wire sensor. - Page 6 8,000 pulses per mile. You should not have to recalibrate your speedometer, unless you have changed the original tire size or the rear end gear ratio. Also, if using the Intellitronix GPS Sending Unit, (S9021 – not included) the speedometer does not need to be calibrated.
-
Page 7: Lifetime Guarantee
9am – 5pm EST (440) 359 – 7200 ext 109 support@intellitronix.com This product carries a limited Lifetime Warranty. This warranty is limited to replacement or repair of the unit at the discretion of Intellitronix. Made in America Lifetime Guarantee AP6001 Intellitronix www.intellitronix.com...
