THORLABS DFB13TK User Manual page 5

Low-Noise DFB Laser System
AC-Coupled Modulation Port Voltage to Current Conversion Rate
AC-Coupled Modulation Laser Wavelength Tuning Range
AC-Coupled Modulation Laser Power Tuning Range
DC-Coupled Modulation Port Voltage to Current Conversion Rate
DC-Coupled Modulation Laser Wavelength Tuning Range
DC-Coupled Modulation Laser Power Tuning Range
Voltage to Temperature Conversion Rate
Input Voltage Range (All Ports)
Input Impedance (All Ports)
AC Current Modulation Frequency Range
DC Current Modulation Frequency Range
Temperature Modulation Frequency Range
a. Specified bandwidth refers to the 3 dB electrical bandwidth of the modulation circuits. Laser response has a slow roll-off for
frequencies above 1 MHz.
Absolute Maximum Output Power
Operating Temperature
Storage Temperature
Input Voltage
Input Power
Dimensions (W x D x H)
Weight
Laser Class
Rev. A, August 16, 2024
Typical External Modulation Specifications
a
a
Absolute Maximum Ratings
General Specifications
Firmware Adjustable
(Default = 0.2 °C/V)
2 kHz to 20 MHz
DC to 5 MHz
145 mW
15 to 35 °C
-10 to 40 °C
12 V (from DS12 Power Supply)
20 W (Max)
10.00" x 5.31" x 2.94"
(254.0 mm x 135.0 mm x 74.6 mm)
4.7 lbs (2.1 kg)
1M
Chapter 1: Introduction
10 mA/V
±0.15 nm
±10 mW
2 mA/V
±0.03 nm
±1 mW
-5 V to 5 V
1 kΩ
DC to 1 Hz
Page 3
