Installing a SIM Card in the HWIC-3G-GSM

To install a SIM card onto the GSM HWIC, follow these steps:
On the bottom side of the 3G wireless HWIC, remove the bracket by unscrewing the M2.5 screw. See
Step 1
Figure 127
Figure 127
1
2
for details.
SIM Card installation Step 1
SIM Card Bracket
SIM socket
Installing a SIM Card in the HWIC-3G-GSM
3
2
1
3
M2.5 screw
